Phoenix Contact DFKMSTB258STF508LR Industrial Feed-through Connector
This feed-through connector features a compact design with 8 positions, a 5.08 mm pitch, and is suitable for industrial automation. It supports a nominal current of 12 A and rated voltage of 320 V, using screw connection with tension sleeve for secure wiring. The connector's tin contact surface ensures good conductivity and corrosion resistance. Made of insulating PA material, it withstands temperatures up to 100°C, with flammability rating UL 94 V-0, making it ideal for versatile industrial applications. Its green housing facilitates easy identification within control panels, ensuring reliable and safe connections in complex systems.
Phoenix Contact DFKMSTB258STF508LR Industrial Feed-through Connector Specifications:
- Number of positions: 8
- Pitch: 5.08 mm
- Nominal current: 12 A
- Rated voltage: 320 V
- Connection method: Screw connection with tension sleeve
- Conductors: Solid and flexible, 0.2 mm² to 2.5 mm²
- Housing material: PA, green color
- Contact surface: Tin-plated
- Flammability rating: UL 94 V-0
- Temperature range: -5°C to +100°C (assembly), -40°C to +70°C (storage/transport)
- Contact resistance: < 1.5 mΩ
- Insulation resistance: > 630 GΩ
- Impact resistance: IEC 60512-13-2 standard, 25 cycles
- Dimensions: Length 19.3 mm, width 16.5 mm, height 16.5 mm
- Approvals: IEC standards, RoHS compliant
Buy the Phoenix Contact DFKMSTB258STF508LR – Reliable Industrial Feed-through Connector for Automation
Order the Phoenix Contact DFKMSTB258STF508LR today to ensure dependable wiring solutions in your automation systems. Designed with robust materials and secure screw connections, this 8-position connector offers excellent electrical performance with a rated voltage of 320 V and current capacity of 12 A. Its compact size, green housing, and tin-plated contacts make it perfect for control panels and industrial environments. Elevate your installation quality by purchasing this high-quality, RoHS-compliant connector easily online and enjoy quick delivery and expert support.
Buy Phoenix Contact DFKMSTB258STF508LR now and experience unmatched reliability and performance with secure screw connections and corrosion-resistant tin contacts.
Frequently Asked Questions
Where can I buy Phoenix Contact DFKMSTB258STF508LR?
You can click on the BUY or RFQ button to purchase DFKMSTB258STF508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part DFKMSTB258STF508LR?
You can download the DFKMSTB258STF508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of DFKMSTB258STF508LR?
Phoenix Contact
