Phoenix Contact FKMCP153ST35LR PCB connector
The FK-MCP 1,5/3-ST-3,5-LR is a compact printed-circuit board connector designed for reliable electrical connections in automation and control systems. Featuring a pitch of 3.5 mm, it supports a rated current of 8 A and a rated voltage of 160 V, with flexible connection options including spring-cage terminals for secure mounting on PCB. The connector’s green insulation and tin contact surface ensure durability and corrosion resistance. Suitable for various industrial applications requiring quick and secure wiring, it complies with UL and VDE standards, ensuring high-quality performance in demanding environments.
Phoenix Contact FKMCP153ST35LR PCB connector Specifications:
- Pitch: 3.5 mm
- Rated current: 8 A
- Rated voltage: 160 V (III/2), 320 V (II/2)
- Contact surface: Tin
- Insulating material: UL 94V-0 inflammability class
- Conductor cross section: solid 0.14 mm² to 1.5 mm², stranded 0.14 mm² to 1.5 mm²
- Stripped conductor min.: 0.14 mm²; max.: 1.5 mm²
- Stranded with ferrule, without plastic sleeve: min. 0.25 mm², max. 1.5 mm²
- With plastic sleeve: min. 0.25 mm², max. 0.5 mm²
- Compatible with AWG 26 to 16
- UL Recognized, cULus Recognized, VDE standard compatible
- Nominal cross section: 1.5 mm²
- Dimensions: a: 7 mm, length: 7 mm, pitch: 3.5 mm
Buy the Phoenix Contact Series FK Series PCB Connector: FK-MCP 1,5/3-ST-3,5-LR
Purchase the Phoenix Contact FK-MCP 1,5/3-ST-3,5-LR online today to ensure secure, quick, and durable electrical connections for your automation and control applications. This high-quality PCB connector supports a rated current of 8 A and voltage of 160 V, with spring-cage terminals for easy wiring. Its compact size of 3.5 mm pitch, tin contacts, and UL and VDE approvals make it ideal for demanding industrial environments. Get reliable connectivity with this versatile and easy-to-install component for professional electronics projects.
Buy Phoenix Contact FK-MCP 1,5/3-ST-3,5-LR now and experience unmatched reliability and performance in industrial PCB connections.
Frequently Asked Questions
Where can I buy Phoenix Contact FKMCP153ST35LR?
You can click on the BUY or RFQ button to purchase FKMCP153ST35LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKMCP153ST35LR?
You can download the FKMCP153ST35LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKMCP153ST35LR?
Phoenix Contact
