SWISSBIT SFSD1024L1BM1TOIDF2A1STD Industrial SDHC Memory Card

The Swissbit S-455 Series industrial SDHC memory card offers high reliability and performance for demanding applications such as navigation, medical devices, and industrial systems. Available in capacities up to 32 GB, it features SD Memory Card specification 3.0 compliance, UHS-I/SDRi04 compatibility, and speeds up to 43MB/sec. Designed for extended temperature ranges from -25°C to 85°C and industrial grades up to -40°C, it includes wear leveling, data care management, and long data retention for long life cycles. Robust build with ESD, water, and dust resistance, plus firmware support and lifetime monitoring ensures durability and data integrity.

Swissbit Series S-455 Industrial SDHC Card: SFSD1024L1BM1TOIDF2A1STD
View SFSD1024L1BM1TOIDF2A1STDDatasheet [pdf]
Authorized Distributors
Source:Mouser Electronics
Part No:SFSD1024L1BM1TO-I-DF-2A1-STD
Stock:0
Inv Date:06-16-2026
Price: N/A
Buy/RFQ:

SWISSBIT SFSD1024L1BM1TOIDF2A1STD Industrial SDHC Memory Card Specifications:

  • Capacities: 512 MB, 1 GB, 2 GB, 4 GB, 8 GB, 16 GB, 32 GB
  • Form Factor: Standard SD (32.0 x 24.0 x 2.1 mm), Write Protect Slider
  • Compliance: SD Memory Card specification 3.0, Speed Class 10, U1, UHS-I/SDRi04 compatible
  • Speed: Up to 43 MB/sec sequential data rate, optimized for random write performance of 1240 IOPS
  • Operating Temp: -25°C to 85°C (extended), -40°C to 85°C (industrial)
  • Storage Temp: -25°C to 100°C (extended), -40°C to 100°C (industrial)
  • Operating Voltage: 2.7V to 3.6V
  • Max Power: 140mA
  • Data Retention: 10 Years at start of life, 1 Year at end of life
  • Shock/Vibration: 1,500 g / 50 g
  • Features: Wear Leveling, Power-off reliability, Data Care, ECC, firmware update, lifetime monitoring
  • Industrial-grade design: dust, water, ESD resistant, qualified to AEC-Q100

Buy the Swissbit Series S-455 Industrial SDHC Card: SFSD1024L1BM1TOIDF2A1STD

Purchase the Swissbit S-455 Series industrial SDHC memory card online for reliable and high-performance data storage. Designed for demanding industrial environments, it supports extended temperature ranges from -40°C to 85°C, ensuring operational stability in harsh conditions. With capacities up to 32 GB, it features high data transfer speeds of up to 43MB/sec, wear leveling, and firmware support for longevity. Ideal for applications requiring durable, high-quality storage including medical devices, navigation systems, and industrial automation, all with quick online ordering convenience.

Get Swissbit S-455 industrial SDHC memory card today—built for high reliability, extended temperature operation, and long-lasting data integrity.

Frequently Asked Questions

Where can I buy SWISSBIT SFSD1024L1BM1TOIDF2A1STD?

You can click on the BUY or RFQ button to purchase SFSD1024L1BM1TOIDF2A1STD from an authorized SWISSBIT distributor.

How do I troubleshoot issues or seek technical support for part SFSD1024L1BM1TOIDF2A1STD?

You can download the SFSD1024L1BM1TOIDF2A1STD datasheet or visit the SWISSBIT website for support.

Who is the manufacturer of SFSD1024L1BM1TOIDF2A1STD?

SWISSBIT
