TDK-LAMBDA DT62PW120D industrial power supply
This high-efficiency external power supply delivers 65W with precise voltage regulation, low ripple, and noise. Designed for industrial and testing applications, it features high power factor correction, UL60950-1 safety certification, and operate effectively between 0 to 70°C. Its compact design measures 69 x 132 x 40 mm, with a convection cooling system, making it ideal for robust, reliable power distribution in demanding environments. The unit also includes continuous short circuit protection and V.5 compliance for energy efficiency.
TDK-LAMBDA DT62PW120D industrial power supply Specifications:
- Input Voltage: 90 - 264VAC, 47 - 63Hz
- Inrush Current: <50A at 115VAC, cold start
- Input Current: 2A at 90VAC
- Power Factor: Typically 0.9 at full load, meets EN61000-3-2
- Leakage Current: 0.7mA at 264VAC
- Hold Up Time: >10ms at 115VAC, full load
- Temperature Coefficient: +0.05%/°C
- Voltage Accuracy: 42%
- Total Regulation: 45%
- Ripple & Noise: 1% or 240mV, whichever is lower
- Overvoltage Protection: 110 - 140% of nominal
- Efficiency: >88% at average load
- Operating Temperature: 0°C to +70°C, derating above 50°C
- Storage Temperature: -10°C to +85°C
- Humidity: 10-90% RH, non-condensing
- Dimensions: 69 x 132 x 40 mm (WxLxH)
- Weight: 400g
- Cooling: Convection
- Safety Certifications: UL60950-1, EN60950-1, IEC60950-1, CE
- Emergency & EMI Compliance: EN55022-B, FCC B, EN55024
- Cable Length: 1050mm with IEC 320-C14 connector
Buy the Buy TDK-Lambda Power Supply Part Number DT62PW120D Online
Purchase the TDK-Lambda DT62PW120D power supply online today to benefit from high efficiency, robust safety features, and compact design. Designed for demanding environments, this 65W unit offers excellent regulation, low ripple noise, and comprehensive protections including short circuit and overvoltage. Ideal for industrial automation, testing, and control systems, it ensures stable operation between 0°C and 70°C. Enjoy quick delivery and secure checkout, making it the perfect choice for professionals seeking dependable power solutions that meet international safety standards.
Buy TDK-Lambda DT62PW120D now and ensure reliable, efficient power delivery for your industrial or testing setup.
Frequently Asked Questions
Where can I buy TDK-LAMBDA DT62PW120D?
You can click on the BUY or RFQ button to purchase DT62PW120D from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part DT62PW120D?
You can download the DT62PW120D datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of DT62PW120D?
TDK-LAMBDA
