TDK-LAMBDA DTM65PW120D Medical Power Supply
This medical-grade power supply delivers 12V at 5A, ensuring reliable and efficient performance for healthcare equipment. Compliant with industry standards, it features low off-load power consumption, high efficiency, and comprehensive safety protections including overcurrent, overvoltage, and overtemperature protection. Compact and robust, it is suitable for critical medical applications requiring stable voltage, minimal ripple, and noise. The power supply is engineered for long-lasting durability, meeting stringent safety and EMC standards to ensure safe operation in medical environments.
TDK-LAMBDA DTM65PW120D Medical Power Supply Specifications:
- Output Voltage: 12V
- Output Current: 5A
- Power Rating: 60W
- Input Voltage Range: 90 - 264VAC (47 - 63Hz)
- Efficiency: >89%
- Protection: Overload, Overvoltage, Overtemperature, Short Circuit
- Ripple & Noise: 120mV pk-pk or greater
- Dimensions: 2.72 x 5.2 x 1.57 inches (69 x 132 x 40mm)
- Weight: 390g
- Operating Temperature: -20 to +60°C (derate starting at 51°C)
- Storage Temperature: -20 to +85°C
- Humidity: 10 - 90% RH
- Cooling: Convection
- Safety Certifications: UL, EN, IEC60601-1, CSA-C22.2 No.60601
- Withstand Voltage: Input to Ground 1.5kVAC, Output to Ground 1.5kVAC
- Vibration (non-operating): < 196.1 m/s²
- Shock: 20G
- Cable Length: 1050mm
- AC Input Connector: IEC 320-C14
- Output Connector: Kycon KPP-4P
- Warranty: Three Years
Buy the TDK-Lambda Series DTM65 Medical Power Supply: DTM65PW120D
Purchase the TDK-Lambda DTM65PW120D medical power supply online today. Designed for healthcare applications, it offers high efficiency, tight voltage regulation, and comprehensive safety protections. With low off-load power consumption and excellent ripple and noise specifications, this durable power supply ensures reliable operation in critical medical devices. Its compact size and IEC320-C14 inlet simplify integration into medical equipment. Enjoy the convenience of quick, secure online ordering with three-year warranty, ensuring peace of mind and sustained medical device performance.
Get TDK-Lambda DTM65PW120D today—built for medical reliability and precision in healthcare environments.
Frequently Asked Questions
Where can I buy TDK-LAMBDA DTM65PW120D?
You can click on the BUY or RFQ button to purchase DTM65PW120D from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part DTM65PW120D?
You can download the DTM65PW120D datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of DTM65PW120D?
TDK-LAMBDA
