TDK-LAMBDA LS2005 industrial power supply
The LS200-5 is a 5V, 200W industrial power supply with a single output, designed for general-purpose applications. It features a wide input voltage range, compact size, internal fan cooling, and a height of 1.6 inches suitable for 1U rack mounting. The power supply provides a fixed output with adjustable capability. It offers low ripple and noise (80mV), a hold-up time of 20ms at 115/230V input, and achieves 72-75% efficiency. Operating temperature range is from -25°C to 70°C. Suitable for industrial, test and measurement, communications, networking, LED lighting, and RF communication applications.
TDK-LAMBDA LS2005 industrial power supply Specifications:
- Input Voltage: 85 - 264VAC, 120 - 373VDC
- Input Frequency: 47 - 63Hz
- Output Voltage: 5V
- Output Power: 200W
- Ripple and Noise: 80mV
- Efficiency: 72-75%
- Hold-Up Time: 20ms
- Operating Temperature: -25°C to 70°C
- Cooling: Internal Fan
- Dimensions: 7.8x3.9x1.61 inches
- Weight: 700g
- Safety Certifications: UL, CSA, IEC 60950-1, CE
- Overcurrent Protection: >105%
- Overvoltage Protection: Yes
- Remote Sense and On/Off: Yes
- Isolation Voltage: Input to Ground 1.5kVAC, Output to Ground 500VAC
- Storage Temperature: -40°C to +85°C
- Operating Humidity: 20-90%, Non-condensing
Buy the Buy TDK-Lambda LS200 Series Part Number LS2005 Online
Purchase the TDK-Lambda LS200 SeriesLS2005 power supply online today for dependable performance in industrial, communication, and test applications. With a compact design, wide input range, internal fan cooling, and adjustable output, this 200W unit offers low ripple and noise, high efficiency, and robust safety features. Perfect for industrial automation, LED lighting, RF, and networking systems, it ensures stable power delivery even in demanding environments. Take advantage of quick online ordering and prompt delivery for your critical projects.
Order your TDK-Lambda SeriesLS200 power supply today and ensure reliable, efficient power for industrial and communication projects.
Frequently Asked Questions
Where can I buy TDK-LAMBDA LS2005?
You can click on the BUY or RFQ button to purchase LS2005 from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part LS2005?
You can download the LS2005 datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of LS2005?
TDK-LAMBDA
