TDK-LAMBDA ZBP Power Supply
The Z+ Series programmable power supplies from TDK-Lambda offer reliable, high-performance DC output options with multiple communication interfaces including USB, RS232, RS485, LAN, and GPIB. Designed for industrial testing and automation, they feature adjustable voltage and current, fast recovery times, excellent line and load regulation, and robust safety standards. Available in various power levels from 200W to 800W with options for rack mounting, these supplies support remote control, analog programming, and precise readback, making them suitable for demanding laboratory, manufacturing, and testing environments.
TDK-LAMBDA ZBP Power Supply Specifications:
- Load Regulation cv 2mV + 0.01% of rated voltage over 0 - 100% load change
- Line Regulation cv 2mV + 0.01% of rated voltage over line change 85 - 132 or 170 - 265VAC
- Recovery Time cv 1ms
- Temperature Coefficient cv 30ppm/°C
- Temperature Stability cv 0.02% of rated voltage over 8 hours
- Warm up Drift cv <0.05% of rated voltage + 2mV
- Load Regulation cc 5mA + 0.01% of rated current
- Line Regulation cc 2mA + 0.01% of rated current
- Voltage & Current Programming Resolution digitally < 0.012% of rated voltage/current
- Voltage & Current Monitoring Accuracy digitally < 0.05%
- Overvoltage Shutdown Vv 0.5-12V to 5-110V depending on model
- Input Voltage 85-265VAC, 47-63Hz
- Cooling variable speed fan
- Size standard body 83 x 70 x 350mm, wide body 83 x 105 x 350mm
- Weight 1.9kg to 2.6kg depending on model
- Warranty 5 years
Buy the TDK-Lambda Series Z+ Power Supply: ZBP
Discover the dependable TDK-Lambda Series ZBP programmable power supplies designed for industrial testing and automation. With multiple communication options including USB, RS232, RS485, LAN, and GPIB, they provide precise voltage and current control, fast recovery times, and excellent regulation. Rugged and reliable, these models support remote operation, analog programming, and meet stringent safety standards. Whether for lab or manufacturing environments, order your TDK-Lambda ZBP power supply online today for consistent, high-quality results in demanding applications.
Order your TDK-Lambda Series ZBP power supply today and ensure your industrial testing projects have reliable, versatile power solutions.
Frequently Asked Questions
Where can I buy TDK-LAMBDA ZBP?
You can click on the BUY or RFQ button to purchase ZBP from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part ZBP?
You can download the ZBP datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of ZBP?
TDK-LAMBDA
