TE CONNECTIVITY 787001500 Aerospace Connector Module
The Deutsch DMC-MD series connectors offer a modular, lightweight, and reliable solution for aircraft in-flight entertainment and cabin systems applications. Designed with a corrosion-resistant composite housing, these connectors support high vibration, salt spray, and temperature ranges from -55°C to +175°C, ensuring durability in aerospace environments. They comply with EN4165, ARINC 809, and BACC65 standards. Available in multiple configurations, including plugs and receptacles with keying options, these connectors enable quick, flexible assembly and secure connections for communication and power systems onboard aircraft.
TE CONNECTIVITY 787001500 Aerospace Connector Module Specifications:
- Housing: Composite, nickel plated
- Modules: Thermoplastic and fluoronated silicone
- Crimp Contacts: Copper alloy, gold plated over nickel
- Temperature Range: -55°C to +175°C
- Vibration: 20 g
- Durability: 500 mating cycles
- Salt Spray Resistance: 500 hours
- Interfacial Sealing: 1.1 x 10^7 bar
- Insulation Resistance: 5000 MΩ
- Contact Current Ratings: Size 24 - 3 A, Size 23 - 5 A, Size 22 - 5 A, Size 20 - 75 A, Size 16 - 13 A, Size 12 - 23 A, Size 8 - 46 A
- EMI Shielding Attenuation: 50 dB at 100 MHz, decreasing with frequency to 30 dB at 1000 MHz
- Weight: Receptacles approx. 0.013-0.015 lbs, Backshells approx. 0.009-0.020 lbs
- Connectors support compatibility with aluminium cable contacts and EN3155-70/71 contacts.
- Designed for panels with 0.8 mm to 2 mm thickness, with recommended screw torque of 0.5 N·m
- Suitable for high-vibration, temperature extreme, and corrosive environments typical in aerospace applications.
Buy the Buy TE Connectivity DMC-MD Series Connector Part Number 787001500 Online
Order the TE Connectivity DMC-MD Series connector part number 787001500 online today. Crafted for aerospace applications, this lightweight, modular connector offers exceptional durability, temperature resistance from -55°C to +175°C, and compliance with industry standards EN4165, ARINC 809, and BACC65. Ideal for aircraft cabin systems, it ensures reliable connections, supporting high vibration and environmental resilience. Benefit from quick installation, keying options, and high EMI shielding. Ensure your aircraft systems are secure and efficient—purchase online now for fast delivery and expert support.
Get TE Connectivity DMC-MD PartNumber 787001500 today—built for high reliability, modularity, and long-lasting durability in aerospace systems.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 787001500?
You can click on the BUY or RFQ button to purchase 787001500 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 787001500?
You can download the 787001500 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 787001500?
TE CONNECTIVITY
