TESTEC TTMF312261102026 High Voltage Differential Probe
The active differential probes are designed for oscilloscopes with bandwidths up to 1.3 GHz, providing precise measurements for high-frequency signals. They feature attenuation ratios of 1:10 to 1:200, input impedances of 4 MΩ//5.5 pF to ground, and maximum input voltages ranging from 70V to 1400V DC/peak AC depending on the model. Rise times are as low as 0.25 ns, with compatible accessories like power supplies, adapters, and test clips included. They support high voltage applications and include hardcases for safe transport, ensuring reliable performance in demanding environments.
TESTEC TTMF312261102026 High Voltage Differential Probe Specifications:
- Bandwidth: up to 1.3 GHz
- Attenuation Ratio: 1:10 to 1:200
- Input Resistance: 4 MΩ // 5.5 pF to ground
- Maximum Input Voltage: 70V to 1400V DC/peak AC depending on model
- Rise Time: as low as 0.25 ns
- Input Capacitance: varies by model, approximately 5 to 15 pF
- Cable Length: 1.2 m
- Dimensions: 111mm x 22mm x 14mm (for smaller models), 202mm x 83mm x 38mm (for larger models)
- Power Supply: 4 x AA Cells or mains adapter 6V or 9V DC
- Weight: between 130g and 500g depending on model
- Operating Voltage: CAT I, up to 2500V peak for high-voltage models
- Response Time: from 0.25 ns to 3.5 ns
- Environmental: Pollution Degree 2, made in Germany
Buy the Buy Testec High Voltage Differential Probe Part Number TTMF312261102026 Online
Discover the reliable performance of the Testec High Voltage Differential Probe TTMF312261102026, designed for oscilloscopes up to 1.3 GHz bandwidth. With attenuation ratios from 1:10 to 1:200 and maximum voltage capacities up to 1400V, it is perfect for high-voltage and high-frequency applications. This probe offers low rise times of 0.25 ns, excellent input impedance, and includes accessories like power supplies, adapters, and durable hardcases for convenient transport. Buy online now to enhance your measurement accuracy in demanding environments.
Order your Testec High Voltage Differential Probe TTMF312261102026 today and ensure accurate high-frequency measurements for demanding testing environments.
Frequently Asked Questions
Where can I buy TESTEC TTMF312261102026?
You can click on the BUY or RFQ button to purchase TTMF312261102026 from an authorized TESTEC distributor.
How do I troubleshoot issues or seek technical support for part TTMF312261102026?
You can download the TTMF312261102026 datasheet or visit the TESTEC website for support.
Who is the manufacturer of TTMF312261102026?
TESTEC
