TRACO POWER TEN30523N Dual Output DC-DC Converter
The TEN 3-0523N from TracoPower is a 3W dual output DC-DC converter housed in a 24-pin DIP package. It serves as a direct replacement for common TEN 3 series converters, featuring an advanced design that reduces costs without sacrificing reliability or functionality. The converter offers a wide input voltage range of 4.5V to 9V DC, with an input current of 65mA at no load. It provides dual outputs of ±15V DC with a maximum current of 100mA per channel, achieving an efficiency of 82%. This converter is equipped with comprehensive input filtering to meet EN 55022 Class A and FCC Level A standards without external components, along with enhanced electromagnetic compatibility (EMC) immunity and an extended operating temperature range from -40°C to +85°C. It includes continuous, automatic recovery short-circuit protection and requires no minimum load. The device features robust protection including EN 61000-4-2 ESD immunity with air ±8KV and contact ±6KV, UL 94V-0 rated epoxy potting, gold-plated copper alloy pins, and high electrical isolation of 1500VDC. Its compact dimensions are 20.3mm x 10.2mm x 31.8mm, with a minimum switching frequency of 90kHz. The converter complies with safety standards IEC 60950-1 and UL 60950-1, and has a start-up voltage of 4.5VDC or lower with a surge voltage of up to 11V for 1 second. Its I/O isolation resistance exceeds 1000 MΩ at 500VDC, with an I/O capacitance of 300pF, and the maximum voltage set accuracy is ±2%. It is suitable for power management and industrial applications.
TRACO POWER TEN30523N Dual Output DC-DC Converter Specifications:
- Input voltage range: 4.5V to 9V DC
- Output voltage: ±15V DC
- Output current max.: 100mA per channel
- Efficiency: 82%
- Input current no load: 65mA at 5V
- Start-up voltage: 4.5VDC or lower
- Surge voltage: 11V max. for 1 sec.
- Ripple and noise: 70 mVpk-pk
- Operating temp: -40°C to +85°C
- Isolation voltage: 1500VDC
- Isolation resistance: >1000 MΩ at 500VDC
- Incorporates input filter for EN 55022 Class A
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Weight: 12.8 g
- Switching frequency: 90 kHz min.
- Protection: Short-circuit, automatic recovery
- Safety standards: IEC 60950-1, UL 60950-1
- Compliance: RoHS, Reach
- Potting material: epoxy (UL 94V-0 rated)
Buy the Traco Power Series TEN 3N DC-DC Converter: TEN30523N
Purchase the TracoPower TEN 3-0523N DC-DC Converter online today to benefit from its high efficiency, extended temperature range, robust protection features, and compliance with international safety standards. Designed to deliver dependable power for industrial automation, instrumentation, and power management systems, this compact 3W converter provides dual outputs of ±15V DC with up to 100mA current per channel. Its advanced electromagnetic compatibility and short-circuit protection make it ideal for demanding environments, ensuring continuous operation without external components. Invest now for premium reliability and peak performance in a compact package.
Order your Traco Power Series TEN 3N DC-DC Converter today and ensure reliable power delivery for industrial and demanding applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN30523N?
You can click on the BUY or RFQ button to purchase TEN30523N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN30523N?
You can download the TEN30523N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN30523N?
TRACO POWER
