TRACO POWER TEN31213N DC-DC Converter
The TEN 3-1213N from Tracopower is a 3W single-output DC-DC converter housed in a 24-pin DIP package. It serves as a drop-in replacement for common TEN 3 series converters, featuring an updated design that reduces costs without sacrificing reliability or functionality. This converter offers a wide 2:1 input voltage range of 9V to 18V DC, with an input current of approximately 35mA at no load. It provides a fixed output voltage of 15V DC with a maximum output current of 200mA and boasts an efficiency of 85%. Its compact dimensions are 20.3mm x 10.2mm x 31.8mm (W x H x D). The unit includes continuous, automatic recovery short circuit protection and requires no minimum load. Certified according to EN 61000-4-2 standards, it has ESD protection with air ±8KV and contact ±6KV (criteria A). The converter features UL 94V-0 rated epoxy potting, a non-conductive FR4 case, and gold-plated copper alloy pins. It provides high reliability with an MTBF exceeding 1 million hours and extended operating temperature capabilities from -40°C to +85°C. Additionally, it has an I/O isolation resistance greater than 1000 MΩ at 500VDC, an I/O capacitance of 300pF, and an isolation voltage of 1500VDC. The start-up voltage is 9V DC or lower, with maximum surge voltage of 25V for 1 second. It complies with various safety standards including IEC 60950-1 and UL 60950-1, and operates with a minimum switching frequency of 90kHz. Suitable for power management and industrial applications, this converter offers robust performance in demanding environments.
TRACO POWER TEN31213N DC-DC Converter Specifications:
- Input voltage range: 9V to 18V DC
- Output voltage: 15V DC
- Output current max.: 200mA
- Efficiency: 85%
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Isolation voltage: 1500VDC
- Isolation resistance: >1000 MΩ at 500VDC
- Isolation capacitance: 300pF
- Start-up voltage: 9V or lower
- Surge voltage: 25V max. for 1 sec.
- Operating temperature: -40°C to +85°C
- Thermal dissipation: 1200mW max.
- Soldering temp.: max. 260°C for 10 sec.
- MTBF: >1 million hours
- Certifications: UL, cUL, IEC 60950-1
- Safety standards: EN 61000-4-2,3,4,5,6
- Switching frequency: ≥90 kHz
Buy the Tracopower Series TEN 3N DC-DC Converter: TEN31213N
Purchase the Tracopower TEN31213N DC-DC converter online today to ensure reliable, efficient power conversion for industrial, automation, and power management systems. Designed with robust safety features, high MTBF, and extensive temperature range, this 3W converter guarantees optimal performance in demanding environments. Its compact size, high efficiency, and UL/IEC certifications make it ideal for various applications requiring stable 15V output, galvanic isolation, and low ripple noise. Get yours now for seamless integration and superior reliability in your electrical setups.
Buy Tracopower TEN31213N now and experience unmatched reliability and performance in your power management applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN31213N?
You can click on the BUY or RFQ button to purchase TEN31213N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN31213N?
You can download the TEN31213N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN31213N?
TRACO POWER
