TRACO POWER TEN32413N DC-DC Converter
The TEN 3-2413N from TracoPower is a 3W single-output DC-DC converter housed in a 24-pin DIP package. Designed as a direct replacement for the standard TEN 3 series, it features an up-to-date design that reduces costs without sacrificing reliability or functionality. This converter offers a wide input voltage range of 18VDC to 36VDC, with an input current of approximately 20mA at no load. It provides a fixed output voltage of 15VDC with a maximum output current of 200mA. The device boasts an efficiency of 85% and a high MTBF exceeding 1 million hours, ensuring high reliability. It complies with multiple safety and EMC standards, including EN 61000-4-2 ESD protection, with immunity to ESD levels of ±8kV air and ±6kV contact, and meets EN 55022 Class A and FCC Level A EMC requirements without external components. The converter has a switching frequency of at least 90kHz, features continuous, automatic short circuit protection, and requires no minimum load. It provides excellent isolation with 1500VDC I/O isolation voltage, greater than 1000MΩ resistance at 500VDC, and 300pF isolation capacitance. The device is housed in a non-conducting FR4 case with UL 94V-0 rated epoxy potting and gold-plated copper alloy pins. Operating over a temperature range from -40°C to +85°C, it is suitable for demanding industrial and power management applications. The start-up voltage is 18VDC or lower, with a maximum surge voltage of 50V for 1 second.
TRACO POWER TEN32413N DC-DC Converter Specifications:
- Power: 3W
- Input Voltage Range: 18VDC to 36VDC
- Output Voltage: 15VDC
- Output Current Max: 200mA
- Efficiency: 85%
- Isolation Voltage: 1500VDC
- Isolation Resistance: >1000MΩ at 500VDC
- Isolation Capacitance: 300pF
- Switching Frequency: ≥90kHz
- Operating Temperature Range: -40°C to +85°C
- Start-up Voltage: 18VDC or lower
- Surge Voltage (1 sec max): 50V
- Ripple and Noise (20 MHz bandwidth): 70mVpk-pk
- Humidity: Up to 95% non-condensing
- Housing Material: Non-conductive FR4, epoxy potting, UL 94V-0
- Pin Material: Copper alloy, gold plated
- Soldering Temperature: Max 260°C for 10 sec
- Weight: 12.8 g
- Safety Standards: IEC/EN 60950-1, UL 60950-1, CSA, CB
- MTBF: >1 million hours
Buy the Buy TracoPower DC-DC Converter Part Number TEN32413N Online
Purchase the TracoPower TEN 3-2413N online today for a highly reliable, compact 3W DC-DC converter suitable for demanding industrial applications. It features an input range of 18VDC to 36VDC, a fixed 15V output, and exceeds safety and EMC standards. Designed with ease of integration in mind, its high efficiency of 85%, robust isolation of 1500VDC, and operating temperature from -40°C to +85°C make it ideal for power management and industrial automation. Order now and benefit from fast delivery and trusted quality.
Get TracoPower TEN 3-2413N today—designed for high reliability, excellent isolation, and efficiency, perfect for industrial power management.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32413N?
You can click on the BUY or RFQ button to purchase TEN32413N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32413N?
You can download the TEN32413N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32413N?
TRACO POWER
