TRACO POWER THD104823N DC/DC Converter
The THD 10 series from Tracopower features 10W compact DC/DC converters in a low-profile 24-pin DIP package. Designed for industrial, instrumentation, and space-constrained applications, these modules offer a wide 2:1 input voltage range, high efficiency up to 88%, minimal ripple, and noise. They include an internal EMI filter, overload, and short circuit protection, supporting input voltages of 12V, 24V, or 48V DC. With an isolation voltage of 1500VDC, operating temperatures from -40°C to +85°C, and certified to UL/cUL 60950-1, they provide reliable power conversion in demanding environments.
TRACO POWER THD104823N DC/DC Converter Specifications:
- Input Voltage Range: 12V, 24V, 48V DC
- Output Voltages: 3.3V, 5.1V, 12V, ±12V, ±15V
- Output Current: Up to 3A or 2A depending on model
- Efficiency: Up to 88%
- Ripple & Noise: 85mV peak-to-peak (20 MHz bandwidth)
- Isolation Voltage: 1500VDC for 60 seconds
- Isolation Capacitance: 1200 pF
- Operating Temperature: -40°C to +85°C
- Switching Frequency: ~400kHz
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Weight: 173g
- Protection: Short circuit, overload, overvoltage
- Certifications: UL/cUL 60950-1, EN 60950-1, IEC 60950-1
Buy the Tracopower Series THD: 10W DC/DC Converter Part PartNumber
Experience reliable power conversion with the Tracopower THD 10 series. These compact 10W DC/DC converters feature a wide input voltage range, high efficiency up to 88%, and built-in protections including short circuit, overload, and overvoltage. Their 1500VDC isolation ensures safe operation in industrial environments, with certifications for UL and IEC standards. Designed for space-conscious applications, they offer minimal ripple and noise, operate efficiently across a broad temperature range, and come with a three-year warranty. Perfect for industrial electronics, instrumentation, and data communication systems needing robust, dependable power solutions.
Get Tracopower THD 10-4823N today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy TRACO POWER THD104823N?
You can click on the BUY or RFQ button to purchase THD104823N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD104823N?
You can download the THD104823N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD104823N?
TRACO POWER
