TRACO POWER TMR62421 DC-DC Converter Module
The TMR 6 series is a highly reliable, compact 6W isolated DC-DC converter module designed for space-critical applications. Featuring a wide 2:1 input voltage range, it offers high efficiency up to 86%, enabling operation from -40°C to +65°C without derating. Encased in a small SIP-8 package, it provides 1600 VDC isolation, remote On/Off control, and short-circuit protection, making it ideal for communication, instrumentation, and industrial electronics where space and performance are crucial. Compliant with RoHS standards, it guarantees durability and safety in demanding environments.
TRACO POWER TMR62421 DC-DC Converter Module Specifications:
- Input Voltage Range: 4.5-9.0 VDC / 9-18 VDC / 18-36 VDC / 36-75 VDC models
- Output Voltage: 3.3 VDC, 5 VDC, 9 VDC, 12 VDC, 15 VDC, 24 VDC, 36-75 VDC options
- Output Current Max: up to 1300 mA depending on model
- Efficiency: Up to 86%
- Isolation Voltage: 1600 VDC
- Operating Temperature Range: -40°C to +65°C
- Dimension: SIP-8 package, 2.0 cm² footprint
- Protection: Short-circuit, automated recovery
- Remote On/Off Control: Yes
- Weight: Approx. 4.8 g
- Certifications: UL 60950-1, RoHS compliant
- Surge Voltage Tolerance: Varies by model, up to 100 Vmax for 48V models
- Ripple & Noise: 50 mVp-p max.
- Start-up Time: Up to 410 ms
- Input Filter: EN 55022 class A/B compliance
- Regulation: ±1% voltage set accuracy, 0.2% regulation tolerance
- MTBF: Greater than 2.1 million hours
Buy the Traco Power Series TMR Series DC-DC Converter: TMR62421
Purchase the Traco Power TMR62421 today and ensure your industrial, communication, or instrumentation project benefits from high efficiency, compact size, and robust isolation. With a 6W power capacity, wide input voltage range, and outstanding reliability, this converter module is perfect for demanding environments. Its low weight, remote On/Off control, and short-circuit protection make it ideal for space-constrained applications requiring high performance and safety. Order now to enhance your project’s power management and operational stability.
Buy Traco Power TMR62421 now and experience unmatched reliability and performance in your space-critical power applications.
Frequently Asked Questions
Where can I buy TRACO POWER TMR62421?
You can click on the BUY or RFQ button to purchase TMR62421 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR62421?
You can download the TMR62421 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR62421?
TRACO POWER
