TRACO POWER THN152410N DC/DC Converter
The THN 15N series is a compact 15-watt DC/DC converter in a 1” x 1” x 0.4” metal package, featuring wide 2:1 input voltage ranges, high efficiency up to 91%, and an internal EN 55032 class A filter. It operates from -40°C to +70°C without derating, supports remote On/Off, and offers precise regulation, overload, overvoltage, and short circuit protections. With a high ingress of safety certifications, it's ideal for space-constrained applications in industrial, communication, and instrumentation equipment, delivering reliable, isolated outputs with low no-load power consumption.
TRACO POWER THN152410N DC/DC Converter Specifications:
- Power: 15 Watt
- Input Voltage Range: Wide 2:1 (9-18 VDC, 18-36 VDC, 36-75 VDC)
- Output Voltage: Adjustable (10-20% for 15 & 24 V models, 10-10% for others)
- Output Current Max: 1500 mA for 5 V, 625-4500 mA for other models
- Efficiency: Up to 91%
- Operating Temperature: -40°C to +70°C without derating
- Isolation Voltage: Input to output 4600 VDC, Input/output to case 1000 VDC
- Ripple and Noise: 75 mVp-p (5V models), 125 mVp-p, 4100 mVp-p (others)
- Protection: Overload, overvoltage, short circuit
- Remote On/Off: Open or 3-15 VDC ON; Short or 0-1.2 VDC OFF
- Safety Standards: IEC/EN/UL 62368-1, EN 55032, EN 55011
- MTBF: 1,670,000 hours
- Switching Frequency: 220-330 kHz
- Physical dimensions: 1” x 1” x 0.4” (25.4 x 25.4 x 10.16 mm)
- Casing Material: Copper, Potting Material: Silicone (UL 94-0 rated)
- Certification: UL, EN, IEC safety and EMC standards
Buy the Traco Power Series THN 15N DC/DC Converter: THN152410N
Purchase the Traco Power THN 15N series DC/DC converter online now to ensure reliable power conversion in industrial, communication, or instrumentation applications. This 15-watt model offers high efficiency up to 91%, wide input voltage options, and comprehensive protections. Its compact size fitting 1” x 1” PCB space makes it ideal for space-critical designs. With remote On/Off features, precise regulation, and certifications like UL 62368-1, this converter guarantees dependable operation in demanding environments. Buy now for fast, secure online availability and expert support.
Get Traco Power THN152410N today—built for precision and long-lasting durability in space-constrained digital systems.
Frequently Asked Questions
Where can I buy TRACO POWER THN152410N?
You can click on the BUY or RFQ button to purchase THN152410N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN152410N?
You can download the THN152410N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN152410N?
TRACO POWER
