TRACO POWER TEN402410E industrial power supply
The TEN 40E series is a 40-watt power supply module designed for industrial applications, offering high efficiency up to 93% and an operating temperature of -40°C to +85°C. It features a compact 2" x 1" metal package with a 6-sided shield, and provides a wide 2:1 input voltage range of 9-18V, 18-36V, or 36-75V DC. The series includes remote on/off, trim functions, and protection features such as short circuit, overvoltage, and overtemperature protection, with safety standards compliance including IEC/EN/UL 62368-1.
TRACO POWER TEN402410E industrial power supply Specifications:
- Power: 40 Watts continuous output
- Input Voltage Range: 9-18V, 18-36V, 36-75V DC (wide 2:1 range)
- Efficiency: Up to 93%
- Operating Temperature: -40°C to +85°C
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V with respective currents
- Isolation Voltage: 1600 VDC I/O isolation
- Protection: Short circuit, overvoltage, overtemperature
- Input Current (no load): 12V: 20mA, 24V: 15mA, 48V: 10mA
- Surge Voltage: 25VDC (12V), 50VDC (24V), 100VDC (48V)
- Remote On/Off: Yes, with adjustable trim
- Safety Standards: IEC 62368-1, UL 62368-1
- Cooling: Natural convection, no derating up to 70°C
- Physical: Metal package 2" x 1", shielded, weight approximately 34g
- Ripple & Noise: 75-150 mVp-p depending on model
- Certification: UL, IEC, EN standards, RoHS compliant
Buy the Traco Power Series TEN 40E 40 Watt Power Supply: TEN402410E
Order the Traco Power TEN402410E online today and enjoy a high-efficiency 40-watt industrial power supply with 93% efficiency, wide input voltage range, and comprehensive safety protections. This compact, shielded metal module features remote on/off, overvoltage, overcurrent, and overtemperature protection, making it ideal for demanding industrial environments. With certifications ensuring compliance with IEC 62368-1 and UL standards, it guarantees reliability, safety, and durability in various applications. Purchase online now for fast delivery and exceptional performance.
Buy Traco Power TEN402410E now and experience unmatched reliability and high efficiency in industrial power applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN402410E?
You can click on the BUY or RFQ button to purchase TEN402410E from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN402410E?
You can download the TEN402410E datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN402410E?
TRACO POWER
