TRACO POWER TEN402410WIE Power Supply
The TEN 40WIE series power supply provides 40 Watts of reliable power with high efficiency up to 93%, operating from -40°C to +70°C without derating. It features a compact 2”x1” metal enclosure with six-sided shielding, a wide 4:1 input voltage range (9-36V or 18-75V DC), and comprehensive protection including short circuit, overvoltage, and overtemperature safeguards. Its isolation rating is 1600 VDC, making it suitable for industrial applications. The series complies with IEC/UL 62368-1 standards, supporting remote on/off functions and having a typical efficiency that minimizes heat development and extends device lifespan.
TRACO POWER TEN402410WIE Power Supply Specifications:
- Power Output: 40 Watts
- Input Voltage Range: 9-36V DC / 18-75V DC (wide 4:1 range)
- Input Surge Voltage: 50V DC at 24V; 100V DC at 48V
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V, -12V, -15V
- Output Power: Max. 40W
- Efficiency: Up to 93%
- Operating Temperature: -40°C to +70°C (model dependent)
- Isolation Voltage: 1600 VDC input/output
- Remote On/Off Control: Yes
- Protection: Short circuit, overvoltage, overtemperature
- Certification: IEC/EN/UL 62368-1
- Dimensions: 2” x 1” x 0.4” (50.8mm x 25.4mm x 10.2mm)
- Weight: 34g
- Electrical Resistance: Isolation resistance min. 1000 MΩ at 500 VDC
- Environmental: Humidity up to 95%, natural convection cooling, UL94 V-0 rated housing
- Start-up Time: 30 ms typical
- Switching Frequency: 250 kHz typical
Buy the Traco Power Series TEN40WIE Power Supply: TEN402410WIE
Discover the high-performance Traco Power Series TEN402410WIE 40 Watt power supply, designed for industrial use with up to 93% efficiency, a wide input range, and full protection features. Its compact, shielded metal enclosure ensures durability and optimal heat dissipation, suitable for challenging environments. With certifications including IEC/UL 62368-1, remote on/off capability, and a robust operating temperature range, this device guarantees stable power delivery. Purchase online today and elevate your industrial applications with dependable, cost-effective power modules engineered for longevity and safety.
Order your Traco Power Series TEN402410WIE power supply today and enhance your industrial projects with reliable, high-efficiency power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TEN402410WIE?
You can click on the BUY or RFQ button to purchase TEN402410WIE from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN402410WIE?
You can download the TEN402410WIE datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN402410WIE?
TRACO POWER
