TRACO POWER TEN32422N Dual output DC-DC converter
The TEN 3-2422N from Traco Power is a compact 3W dual output DC-DC converter housed in a 24-pin DIP package. It replaces the original TEN 3 series with an improved design that reduces costs while maintaining high reliability and functionality. It accepts an input voltage range of 18V to 36V DC, providing dual outputs of ±12V DC with a maximum load of ±125mA and an efficiency of 84%. The unit features integrated input filtering to meet EMC standards (EN 55022, FCC Level A), extended operating temperature from -40°C to +85°C, and high MTBF over 1 million hours. Safety approvals include UL, cUL, IEC, and more, making it ideal for cost-sensitive industrial environments requiring dependable voltage regulation and power isolation.
TRACO POWER TEN32422N Dual output DC-DC converter Specifications:
- Input Voltage Range: 18V to 36V DC
- Output Voltage: ±12V DC
- Output Current: ±125mA (max.)
- Efficiency: 84%
- Isolation Voltage: 1500VDC
- Input Current No Load: 20mA
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -55°C to +125°C
- MTBF: >1,000,000 hours
- Dimensions: 20.3 mm x 10.2 mm x 31.8 mm
- Housing Material: Non-conductive FR4
- Soldering Temperature: Max. 260°C / 10 sec.
- Safety Certifications: UL, cUL, IEC/EN 60950-1
- Switching Frequency: 90 kHz min.
- Isolation Resistance: >1,000 MΩ at 500VDC
- Maximum Capacitive Load: 220 pF for 12V model, 150 pF for 15V model, etc.
- Input Ripple & Noise: 70 mVpk-pk (20 MHz bandwidth)
- Protection: Continuous short circuit, automatic recovery
- Compliance: RoHS, REACH
Buy the Traco Power TEN 3-2422N – Reliable Dual Output Power Supply for Industrial Applications
Buy the Traco Power TEN 3-2422N online now for a compact, reliable dual output power solution suitable for demanding industrial environments. This 3W DC-DC converter features dual ±12V outputs with 125mA max. load, 84% efficiency, and an operating temperature range from -40°C to +85°C. Its high isolation voltage of 1500VDC ensures safety and performance. It meets EMC standards and is certified UL, cUL, and IEC for safety. Ideal for power management in industrial automation, instrumentation, and telecom applications, ensuring high reliability and optimal power conversion in a small form factor.
Order your Traco Power series TEN 3-2422N today and give your projects the dependable voltage regulation they deserve with proven reliability.
