TRACO POWER TSR124120 DC-DC Power Converter
The POWER TSR-1 series is a highly efficient DC/DC step-down power converter delivering up to 96% efficiency. Designed to replace linear regulators like the LM78xx, it operates from 4.6 to 36 VDC input and provides a stable output from 1.2V to 33V, supporting output currents up to 1A. Its high efficiency allows operation at ambient temperatures up to +60°C without heatsinks or cooling. Features include low standby current of 2mA, built-in filtering capacitors, and robust short-circuit protection, making it ideal for battery-powered and demanding electronics applications, ensuring reliable and consistent performance over extended use.
TRACO POWER TSR124120 DC-DC Power Converter Specifications:
- Input Voltage Range: 4.6 - 36 VDC
- Output Voltage Options: 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5.0V, 6.5V, 9.0V, 12V, 15V
- Maximum Output Current: 1A
- Efficiency: up to 96%
- Standby Current: 2mA
- Operating Temperature: -40°C to +85°C (derating above +60°C)
- Ripple Voltage: 50mV (models 1.2V to 6.5V), 75mV (models 9V to 15V)
- Short-circuit protection: Yes, automatic restart
- Isolation Voltage: None specified
- Switching Frequency: approximately 500kHz
- Mechanical Dimensions: 11.7 mm x 25.4 mm x 20 mm
- Material: UL 94V-0 rated silicone encapsulation
- Weight: 19 grams
- Input Capacitors: 22 pF / 50 V (for input filtering)
- Output Regulation: ±2%
- Temperature Coefficient: +0.015%/°C max
- Thermal Shock Resistance: MIL-STD-810F
- Humidity Resistance: Up to 95% RH
- MTBF: Over 5.35 million hours
Buy the Buy TracoPower DC Power Module Part Number TSR124120 Online
Purchase the TracoPower TSR124120 DC-DC power converter online today and benefit from its high efficiency of up to 96%, wide input voltage range, and robust short-circuit protection. This 1A step-down module offers outstanding performance for battery-powered devices and demanding electronic applications. With built-in filtering, low standby power consumption, and a compact design, it's perfect for engineers and technicians seeking reliable and efficient power solution. Get yours now and improve your project’s energy efficiency and long-term stability!
Order your TracoPower TSR124120 series high-efficiency power converter today and ensure your electronics operate reliably with excellent thermal performance.
Frequently Asked Questions
Where can I buy TRACO POWER TSR124120?
You can click on the BUY or RFQ button to purchase TSR124120 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TSR124120?
You can download the TSR124120 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TSR124120?
TRACO POWER
