TRACO POWER TEN402425WIE DC/DC Converter
The TEN 40WIE is a versatile industrial DC/DC converter delivering 40 watts with high efficiency up to 93%. Its compact 2x1-inch metal package features a 4:1 input voltage range (9-36 VDC, 18-75 VDC), making it suitable for diverse applications. It offers excellent temperature capabilities from -40°C to +85°C, with full certification including IEC/EN/UL 62368-1. Additional features include remote on/off, overvoltage, overtemperature, and short circuit protections. Designed for reliability, this series ensures stable performance in harsh environments, ideal for industrial and automation systems.
TRACO POWER TEN402425WIE DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC and 18-75 VDC (4:1 ratio)
- Output Power: 40 Watts
- Efficiency: up to 93%
- Operating Temperature: -40°C to +85°C
- Isolation Voltage: 1600 VDC input/output
- Protection: Short circuit, overvoltage, overtemperature
- Dimensions: 2 inch x 1 inch x 0.4 inch (50.8mm x 25.4mm x 10.16mm)
- Cooling: Natural convection
- Remote On/Off: Yes
- Temperature Coefficient: +0.02%/K max.
- Start-up Time: 30 ms typical
- Safety Standards: IEC/EN/UL 62368-1
- Vibration Resistance: MIL-STD-810F
- Weight: 34 g
- Insulation Resistance: 1000 MOhm min at 500 VDC
- Isolation Voltage: 11131 VAC input/output for 60s
- Certifications: UL, IEC 62368-1, IEC 61000 EMI compliance
Buy the Traco Power Series DC/DC Converter: TEN 40WIE 40W
Order the Traco Power TEN 40WIE series DC/DC converter online today and experience dependable power conversion with efficiencies up to 93%. Its wide input voltage range and robust protections make it perfect for industrial, automation, and mission-critical systems. The compact 2x1-inch design saves space while delivering 40 watts of reliable power. With certifications including IEC/EN/UL 62368-1, this converter ensures safety and compliance. Elevate your project's performance—purchase now for fast delivery and expert support.
Get Traco Power TEN 40WIE 40W today—built for industrial reliability and high efficiency in demanding applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN402425WIE?
You can click on the BUY or RFQ button to purchase TEN402425WIE from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN402425WIE?
You can download the TEN402425WIE datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN402425WIE?
TRACO POWER
