TRACO POWER TEN404815E DC/DC Converter
The TEN 40E Series is a 40-watt industrial DC/DC converter designed for high efficiency and reliable performance across a wide temperature range of -40°C to +85°C. Encased in a compact 2”x1” metal package with a 6-side shield, it features a 2:1 input voltage range (9-75 VDC), high efficiency up to 93%, and comprehensive protections including short circuit, overvoltage, and overtemperature. Certified according to IEC/EN/UL 62368-1 standards, it offers remote on/off, trim functions, and is suitable for demanding industrial applications requiring stable power with minimal heat development and environmental resilience.
TRACO POWER TEN404815E DC/DC Converter Specifications:
- Power: 40 Watts
- Input Voltage Range: 9-18 VDC, 18-36 VDC, 36-75 VDC, with 2:1 wide input ratio
- Output Voltage Options: 3.3 V, 5 V, 12 V, 15 V, 24 V, -12 V, -15 V, -24 V, 15 V / -15 V, 12 V / -12 V, 24 V / -24 V
- Output Power: Up to 40 Watts, with adjustable output voltage from -10% to +20% for some models
- Efficiency: Up to 93%
- Temperature Range: -40°C to +85°C (operation), -40°C to +70°C (full load, model dependent)
- Isolation: 1600 VDC I/O-isolation, insulation test voltage 1131 VAC
- Protection: Short circuit, overvoltage, overtemperature, automatic recovery
- Dimensions: 2” x 1” x (height varies), housing of metal with shielded construction
- Input Current: 20 mA at no load (12 V), 15 mA (24 V), 10 mA (48 V)
- Input Surge Voltage: 25-100 VDC depending on model
- Remotes & Control: Remote On/Off, Trim Function, inverse remote control support
- Safety & Standards: IEC 62368-1, UL 62368-1, EN 62368-1
- Compliance: RoHS, REACH, MIL-STD-810F reliability certification
- Operating Temperature: -40°C to +85°C
- Housing Material: Copper
- Connection Type: Through-hole
- Weight: 34 grams
Buy the Traco Power Series TEN 40E DC/DC Converter: TEN404815E
Experience reliable power with the Traco Power Series TEN 40E DC/DC Converter. Designed for industrial use, it delivers 40 watts with high efficiency up to 93%, ensuring minimal heat. Featuring a wide input voltage range of 9-75 VDC, it offers multiple output options, remote on/off, and comprehensive protections against short circuits, overvoltage, and overheating. Its robust construction in a compact metal package makes it suitable for demanding environments, providing stable voltage and enhanced safety standards for various industrial applications. Buy online today for trusted power solutions.
Order your Traco Power Series TEN 40E 48 VDC Power Supply today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy TRACO POWER TEN404815E?
You can click on the BUY or RFQ button to purchase TEN404815E from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN404815E?
You can download the TEN404815E datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN404815E?
TRACO POWER
