TRACO POWER TEN82410 DC/DC Converter Module
The TEN 8-2410 is a high-performance 8W DC/DC converter module with a wide 2:1 input voltage range. It features high efficiency, allowing operation across a temperature range of -40°C to 85°C. The module includes a built-in EMI input filter that complies with EN 55022, Class A, without the need for external components. Standard features comprise a 3.3V DC output voltage, an input voltage range of 18 to 36V DC, remote ON/OFF control, and short-circuit protection. Encased in a shielded metal casing with an insulated base plate, it is suitable for battery-powered equipment and applications requiring isolated, tightly regulated voltages in space-constrained PCB environments.
TRACO POWER TEN82410 DC/DC Converter Module Specifications:
- Input voltage range: 18-36 VDC
- Output voltage: 3.3 VDC
- Output current max.: 2,000 mA
- Efficiency: High efficiency for full temperature range
- Operating temperature: -40°C to +85°C
- Input filter compliance: EN 55022, Class A
- Isolation Voltage: 1500 VDC
- Isolation resistance: >1000 MOhm
- Housing: Shielded metal casing
- Baseplate: Insulated plastic
- Dimension: Compact DIP-24 package
- Protection: Short-circuit, overcurrent
- Remote ON/OFF control: Yes
- RoHS compliant, lead-free design
- Soldering temperature max.: 265°C for 10 sec.
- Weight: 17 grams
Buy the TracoPower TEN 8-2410 – Reliable DC/DC Converter for Industrial Applications
Purchase the TracoPower TEN 8-2410 online to ensure a reliable, efficient power solution for industrial electronics, instrumentation, and communication devices. This 8W high-performance DC/DC converter features a wide input voltage range of 18 to 36V DC, a stabilized 3.3V output, and built-in EMI filtering compliant with EN 55022, Class A, eliminating external components. Its compact shielded metal casing with insulated baseplate guarantees durability and safety. Ideal for space-constrained applications needing isolated, tightly regulated voltages, the TEN 8-2410 offers short-circuit protection, remote ON/OFF, and excellent thermal performance, making it the perfect choice for demanding environments.
Get TracoPower TEN 8-2410 today—built for precision, high efficiency, and long-lasting durability in industrial and battery-operated electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TEN82410?
You can click on the BUY or RFQ button to purchase TEN82410 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN82410?
You can download the TEN82410 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN82410?
TRACO POWER
