TRACO POWER TEN64811N 6W DC-DC Converter
The TEN 6-4811N from TracoPower is a high-performance, single-output, 6W DC-DC converter in a 24-pin DIP package. Designed for optimal cost-to-performance ratio, it features overload protection, internal filtering compliant with EN55022 Class A, no minimum load requirement, and high efficiency. The converter is a drop-in replacement suitable for many cost-sensitive applications, with a wide input voltage range of 36VDC to 75VDC and a 2:1 input tolerance. It provides a stable 5VDC output with a maximum current of 1200mA, boasting an efficiency of approximately 80%. The device offers continuous, automatic recovery short-circuit protection, high input-to-output isolation of 1500VDC, and adheres to UL and IEC safety standards. Its compact dimensions are 20.3mm x 10.2mm x 31.8mm, and it operates reliably across temperatures from -40°C to +85°C. Typical applications include power management, industrial equipment, workstations, computers, and communications systems.
TRACO POWER TEN64811N 6W DC-DC Converter Specifications:
- Input voltage range: 36VDC to 75VDC
- Output voltage: 5VDC
- Output current max.: 1200mA
- Efficiency: approximately 80%
- Input current at full load: 610mA (24V) models
- Isolation voltage: 1500VDC
- Operating temperature: -40°C to +85°C
- Dimensions: 20.3 mm x 10.2 mm x 31.8 mm
- Protection: overload, automatic recovery short-circuit
- Safety standards: UL/cUL 60950-1, IEC/EN 60950-1
- Certifications: UL, IEC, RoHS compliant
- Reliability MTBF: >1 million hours
- Soldering temperature (max): 260°C
- No minimum load required
- Internal filter: meets EN 55022 Class A
Buy the TracoPower Series TEN 6-4811N Voltage Converter: TEN64811N
Purchase the TracoPower TEN 6-4811N online today to ensure reliable power conversion with high efficiency, wide input voltage range, and safety compliance. Ideal for industrial, communication, and computing power systems, this converter offers robust overload and short circuit protection, minimal noise, and operates reliably across temperatures from -40°C to +85°C. Its compact, easy-to-integrate DIP-24 package makes it suitable for space-constrained and cost-sensitive applications. Buy now to enhance your power management solutions with a proven, durable, and efficient device designed for demanding environments.
Get TracoPower TEN 6-4811N today—built for precision and long-lasting durability in power management applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN64811N?
You can click on the BUY or RFQ button to purchase TEN64811N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN64811N?
You can download the TEN64811N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN64811N?
TRACO POWER
