TRACO POWER TEPHS1 dc-dc converter
The TEP 75 series is a rugged, high-performance DC/DC converter module offering 75 Watts in a sealed metal case with ultra-wide 4:1 input voltage range. Designed for industrial applications, it features chassis mounting options, remote On/Off, and output voltage trimming. The modules deliver high efficiency, operate up to +60°C without derating, and include protections such as undervoltage lockout and reverse input voltage protection. Suitable for both chassis mounting and PCB integration, these converters are ideal for automation, railway, and battery-powered systems, complying with safety and EMI standards.
TRACO POWER TEPHS1 dc-dc converter Specifications:
- Input Voltage Range: 5.0 VDC to 160 VDC
- Output Voltage: 5.0 VDC to 48 VDC
- Output Current Max: 634 A (12 VDC), 50 A (15 VDC), 274 A (28 VDC), 16 A (48 VDC)
- Efficiency: Up to 91%
- Operating Temperature: Up to +60°C with convection cooling
- Output Voltage Adjustment: +10% / -20%
- Ripple & Noise (20 MHz Bandwidth): 100 mVp-p (5V), 250 mVp-p (24V), 350 mVp-p (48V)
- Protections: Undervoltage lockout, reverse input voltage, short circuit, overvoltage
- Isolation Voltage: 2,250 VDC (input/output)
- Safety & EMC Standards: UL 60950-1, EN 50155, EN 55022 Class A, EN 61000-4-x immunity
- Dimensions: Modules with chassis mounts approx. 2.4 in x 0.68 in x 1.1 in (mm: 50.8 x 17.3 x 28.0)
- Weight: 97 g (module), 135 g (with heatsink)
Buy the Buy Traco Power TEP 75WI Series Part Number TEPHS1 Online
Purchase the Traco Power TEP 75WI Series DC/DC converter module online today. Featuring rugged metal casing, ultra-wide input voltage, high efficiency, and protections including undervoltage lockout and reverse voltage. Ideal for industrial, railway, and battery systems, this 75W power supply ensures reliable performance with adjustable output voltage, remote On/Off, and compliance with safety standards. Get fast delivery and trusted quality for your critical applications, boosting your system's stability and protection with minimal effort.
Order your Traco Power TEP 75WI Series TEPHS1 today and enhance your industrial or railway projects with reliable, high-efficiency DC/DC conversion.
Frequently Asked Questions
Where can I buy TRACO POWER TEPHS1?
You can click on the BUY or RFQ button to purchase TEPHS1 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEPHS1?
You can download the TEPHS1 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEPHS1?
TRACO POWER
