TRACO POWER TEN54812WI DC/DC Converter Module
The POWER TEN 5WI Series is a high-performance 6 Watt DC/DC converter family designed for industrial, communication, and instrumentation applications requiring wide input voltage ranges of 9 to 36 VDC or 18 to 75 VDC. Featuring a DIP-24 package, high efficiency up to 83%, and a wide operating temperature range from -40°C to +85°C, these modules offer excellent load and line regulation, 1500VDC isolation, and built-in filtering to meet international standards. They are fully RoHS compliant with a 3-year warranty, ideal for battery-powered systems and distributed power architectures.
TRACO POWER TEN54812WI DC/DC Converter Module Specifications:
- Input voltage range: 9-36 VDC or 18-75 VDC
- Output voltage: 12 VDC
- Output current max.: 500 mA
- Efficiency: 83%
- Isolation voltage: 1500 VDC
- Operating temperature: -40°C to +85°C
- Temperature coefficient: 0.02 %/K
- Ripple and noise: 80 mVpk-pk
- Case material: Black anodized aluminium
- Dimensions: Not specified in text, standard DIP-24 footprint
- Weight: 17 g
- Protection: Short circuit, reverse polarity
- Switching frequency: 450 kHz
- Certifications: UL/IEC 60950-1, RoHS
- Soldering temperature: max 260°C for 10 sec
Buy the Trac Series TEN54812WI DC: 12 VDC Power Converter Module
Discover the Trac Series TEN54812WI DC/DC converter, a high efficiency, 12 V output power module with 1500VDC isolation, wide voltage range, and robust design. Perfect for industrial, communication, or instrumentation applications, it features a compact DIP-24 package, excellent load regulation, and comprehensive safety standards. With a temperature range of -40°C to +85°C, this converter provides dependable power in challenging environments. Order online today to benefit from fast delivery, technical support, and excellent warranty coverage, ensuring optimal performance for your power needs.
Buy Trac TEN54812WI now and experience reliable power supply with high efficiency and wide input voltage suitability for industrial electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TEN54812WI?
You can click on the BUY or RFQ button to purchase TEN54812WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN54812WI?
You can download the TEN54812WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN54812WI?
TRACO POWER
