TRACO POWER TEL104812WI DC-DC Converter
The TEL 10WI series offers compact, high-efficiency isolated DC/DC converters with a power density of 3.83 W/cm². In a DIP-16 metal casing with an insulated base, these converters support input voltages from 4:1 wide ranges, up to 87-88% efficiency, and operate at temperatures from -40°C to +88°C. Designed for space-critical and cost-sensitive applications, they feature built-in filters, short circuit protection, and high EMI immunity, making them ideal for industrial electronics, instrumentation, and IT equipment.
TRACO POWER TEL104812WI DC-DC Converter Specifications:
- Power: 10 Watts
- Input Voltage Range: 4:1 wide range (e.g., 9-36 VDC, 18-75 VDC)
- Output Voltage Options: 3.3 V, 5.1 V, 12 V, 15 V, 24 V, etc.
- Maximum Output Current: 416 mA to 2700 mA depending on model
- Efficiency: up to 88%
- Operating Temperature: -40°C to +88°C
- Isolation Voltage: 1500 VDC input to output
- Dimensions: DIP-16 metal casing, 17.78 mm x 21.59 mm x 10.16 mm
- Environmental Standards: EN 55032 Class A, FCC part 15 Class A
- Switching Frequency: 355-485 kHz
- Reliability MTBF: 2,540,000 hours
- Pin Material: Tinned copper, epoxy potting
Buy the Traco Power Series TEL 10WI DC-DC Converter: TEL104812WI
Purchase the Traco Power TEL 10WI series DC-DC converter online today and benefit from a compact design, high efficiency up to 88%, and wide input voltage range. Ideal for industrial electronics, instrumentation, and cost-sensitive applications, these converters feature built-in filters, short circuit protection, and high EMI immunity. With a robust DIP-16 metal casing, they deliver reliable performance across temperatures from -40°C to +88°C, ensuring seamless operation in demanding environments. Order now for fast delivery and secure power solutions.
Buy Traco Power TEL 10WI series converter now and experience unmatched reliability and high-efficiency power solutions for space-sensitive applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEL104812WI?
You can click on the BUY or RFQ button to purchase TEL104812WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL104812WI?
You can download the TEL104812WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL104812WI?
TRACO POWER
