TRACO POWER TEPMK1 High Power DC-DC Converter
The TEP 75WI Series consists of rugged, compact 75-watt isolated DC/DC converters designed for industrial and railway applications. Encased in a sealed metal case, these converters feature an ultra-wide 4:1 input voltage range, high efficiency, and thermal management options such as chassis mounting and heatsinks. Suitable for board or chassis mounting, they include optional input filters, remote on/off, and overvoltage protection. These converters meet various safety and EMC standards, providing reliable performance in demanding environments with an operating temperature up to +60°C.
TRACO POWER TEPMK1 High Power DC-DC Converter Specifications:
- Input Voltage Range: 5.0 VDC to 43 - 160 VDC, ultra-wide 4:1 ratio
- Output Power: 75 Watts
- Efficiency: up to 91%
- Input Current at No Load: 85 - 185 mA depending on model
- Input Current at Full Load: up to 3600 mA at 24 V
- Start-up Voltage: 9 VDC to 43 VDC depending on model
- Surge Voltage: 50 V to 185 V max.
- Ripple and Noise: 100-350 mVp-p depending on output voltage
- Operating Temperature: -40°C to +75°C (derating above +60°C)
- Isolation Voltage: 2250 VDC (input/output)
- Protection: Reverse polarity, overvoltage, short circuit
- Connectivity: Screw terminals, optional chassis mounting with heatsink and DIN-rail clip
- Compliance: UL 60950, EN 50155, EN 55032, EN 61000-4 series
- Thermal impedance: 6.7 K/W without heatsink, 47 K/W with heatsink
- MTBF: 336,000 hours at +70°C
Buy the Traco Power Series TEP 75WI High Power DC-DC Converter: TEPMK1
Purchase the Traco Power TEP 75WI Series high-efficiency 75-watt DC-DC converter online today. This rugged, compact module offers wide input voltage compatibility, excellent thermal management with optional heatsinks, and mounts easily on chassis or DIN rails. Designed for industrial and railway applications, it features overload protection, remote on/off, and high EMC compliance. Reliable and durable, this converter guarantees stable power delivery in challenging environments. Upgrade your system now by ordering online and ensure seamless, dependable operation for your demanding projects.
Order your Traco Power Series TEP 75WI high power DC-DC converter today and give your industrial systems the dependable, high-efficiency power they need.
Frequently Asked Questions
Where can I buy TRACO POWER TEPMK1?
You can click on the BUY or RFQ button to purchase TEPMK1 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEPMK1?
You can download the TEPMK1 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEPMK1?
TRACO POWER
