TRACO POWER THD104813WIN DC-DC Converter
The THD 10-4813WIN from Traco Power is a 10W DC-DC converter in a 24-pin DIP package, featuring an internal EMI filter compliant with EN55022, Class A. It provides high efficiency around 87%, no minimum load, and overload protection. Operating over 18V to 75V input, it offers a 15V output at 666mA, with an I/O isolation of 1500VDC. Designed for industrial and communication uses, it withstands temperatures from -40°C to +85°C, ensuring reliable, space-efficient performance in cost-sensitive applications with high safety standards.
TRACO POWER THD104813WIN DC-DC Converter Specifications:
- Input voltage range: 18VDC to 75VDC
- Output voltage: 15VDC
- Output current: 666mA
- Efficiency: approximately 87%
- Isolation voltage: 1500VDC
- Operating temperature: -40°C to +85°C
- Storage temperature: -55°C to +125°C
- Humidity: 95% non-condensing
- Case material: Metal with non-conductive baseplate
- Pin material: Copper alloy with gold plating
- Soldering temperature: Max 260°C for 10 sec.
- Dimensions: See datasheet for dimensions
- Safety Standards: UL/cUL 60950-1, IEC/EN 60950-1
- Certifications: IEC, UL, CSA, CB
- Designed for space-constrained, cost-sensitive industrial applications
Buy the Buy Traco Power THD 10-4813WIN Part Number THD104813WIN Online
Order the Traco Power THD 10-4813WIN today online to enjoy a compact, high-efficiency DC-DC converter with 15V output, 1500VDC isolation, and robust safety features. Designed for industrial and communication applications, this 10W converter operates reliably from -40°C to +85°C, ensuring optimal performance in space-constrained, cost-sensitive projects. With UL/cUL and IEC certifications, it's ideal for demanding environments needing durable, space-efficient power solutions with low noise and high load capacity, making it a perfect choice for engineers seeking dependable power conversion.
Get Traco Power THD 10-4813WIN today—built for high efficiency, reliability, and safe operation in industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER THD104813WIN?
You can click on the BUY or RFQ button to purchase THD104813WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD104813WIN?
You can download the THD104813WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD104813WIN?
TRACO POWER
