TRACO POWER TEN61210N Industrial Power Converter
The TEN 6-1210N from TracoPower is a high-performance, single-output 6W DC-DC converter housed in a 24-pin DIP package. It is designed for an optimal balance of cost and performance for various power conversion applications. This converter features overload protection, an internal filter conforming to EN55022 Class A standards, no minimum load requirement, and high efficiency. It is a drop-in replacement for many cost-sensitive applications, utilizing a popular DIP-24 package. The device supports a wide input voltage range of 9V to 18V DC, with an input current of approximately 40mA at no load, and provides a stabilized 3.3V DC output with a maximum current of 1200mA. It offers an efficiency of around 75%, with input/output isolation of 1500VDC and excellent voltage regulation within ±2%. The switch-mode power supply operates at a frequency of 330kHz, with automatic, continuous short-circuit recovery and no minimum load needed. Encased in a UL 94V-0 rated plastic case with UL 94V-0 rated epoxy potting, it is compliant with safety certifications UL/cUL 60950-1 and IEC/EN 60950-1. The converter can handle surge voltages up to 25V (1 second max), with a start-up voltage of 9VDC or lower. Its high isolation resistance exceeds 1000 MΩ at 500VDC, with an I/O capacitance below 1000pF. Its dimensions are 20.3mm x 10.2mm x 31.8mm, and it operates across temperatures from -40°C to +85°C. Common applications include power management, industrial equipment, workstations, computers, and communication devices.
TRACO POWER TEN61210N Industrial Power Converter Specifications:
- Power: 6 Watts
- Input Voltage Range: 9V to 18V DC
- Output Voltage: 3.3V DC
- Output Current Max: 1200mA
- Efficiency: 75%
- Isolation Voltage: 1500VDC
- Operating Temperature Range: -40°C to +85°C
- No Minimum Load Required
- Input Filter: EN 55022 Class A
- Surge Voltage: 25V (1 sec max)
- Switching Frequency: 330kHz
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Case Material: UL 94V-0 plastic
- Certification: UL/cUL 60950-1, IEC/EN 60950-1
- Isolation Resistance: >1000 MΩ at 500VDC
- Ripple & Noise: 80mVp-p max
- Line Regulation: ±0.5%
- Load Regulation: ±1.2%
- Ambient Temperature Range: -40°C to +85°C
- Humidity: 95% rel H max
- MTBF: >1 million hours
Buy the TracoPower TEN-6N – Reliable Power Supply for Industrial Applications
Purchase the TracoPower TEN-6N today for your industrial and communication systems. This high-efficiency 6W DC-DC converter offers a wide input range from 9V to 18V, ensuring stable 3.3V output at up to 1200mA. Featuring overload protection, high insulation, and no minimum load requirement, it’s suitable for industrial, power management, and equipment applications. Its compact DIP-24 package simplifies integration in various environments, providing reliable operation across temperatures from -40°C to +85°C. Order now to ensure your systems operate with durable and efficient power conversion.
Get TracoPower TEN-6N today—built for industrial power and long-lasting reliability.
Frequently Asked Questions
Where can I buy TRACO POWER TEN61210N?
You can click on the BUY or RFQ button to purchase TEN61210N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN61210N?
You can download the TEN61210N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN61210N?
TRACO POWER
