TRACO POWER THD122411WI DC/DC Converter
The THD 12WI series is a compact, high-performance 12W isolated DC/DC converter module designed for industrial electronics, instrumentation, and data communication systems. Featuring ultra-wide 4:1 input range, high efficiency up to 85%, and guaranteed reliability, this unit includes key features such as remote On/Off, dual and single output options, built-in filters, and robust short-circuit protection. Its copper shielded case with insulated baseplate ensures durability and effective EMI shielding, operating reliably from -40°C to +85°C, perfect for space-constrained applications requiring stable power conversion.
TRACO POWER THD122411WI DC/DC Converter Specifications:
- Input Voltage Range: 3.3 VDC to 36 VDC, 9 VDC to 36 VDC, and 18 VDC to 75 VDC options
- Output Power: 12W, with various output voltages including 3.3 V, 5.1 V, 12 V, and 15 V
- Efficiency: up to 85%
- Isolation Voltage: 1500 VDC
- Operating Temperature: -40°C to +85°C
- Dimensions: 25.4 mm x 20.32 mm x 10.16 mm (1.00 in x 0.80 in x 0.40 in)
- Protection Features: Short-circuit, overload, and overvoltage protection
- Switching Frequency: 400 kHz typical
- Quality Standards: UL60950-1, IEC/EN 60950-1, RoHS compliant
- Input Surge Voltage: Up to 100 V max., Start-up voltage: +9 VDC to +18 VDC depending on model
- Pin configuration: Remote On/Off, Vin, Vout, GND, with optional NTC control
- Reliability: MTBF > 2 million hours at +25°C
Buy the Buy TracoPower DC/DC Converter Part Number THD122411WI Online
Purchase the TracoPower THD122411WI isolated DC/DC converter online to benefit from high efficiency, ultra-wide input voltage, and robust protection features. Designed for demanding industrial environments, this 12W power module offers excellent reliability, compact size, and ease of installation. With built-in filters, remote On/Off, and high isolation voltage, it’s ideal for space-constrained applications that require stable and safe power supplies. Order now to enhance your electronics with trusted performance and quick delivery from authorized distributors.
Order your TracoPower SeriesTHD122411WI 12W isolated power module today and ensure reliable, efficient power in your industrial or communication project.
Frequently Asked Questions
Where can I buy TRACO POWER THD122411WI?
You can click on the BUY or RFQ button to purchase THD122411WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD122411WI?
You can download the THD122411WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD122411WI?
TRACO POWER
