TRACO POWER THI31211 High Isolation DC/DC Converter
The THI 3 series is a high isolation DC/DC converter designed for medical and industrial applications, offering reinforced insulation up to 4000 VACrms rated for 300 VACrms working voltage. Encapsulated in a DIP-24 package, these fully regulated converters support input voltages of 5, 12, and 24VDC, with single or dual outputs. They meet safety standards including IEC/EN 60601-1 and IEC/EN 60950-1, providing low leakage current, short circuit protection, and excellent thermal performance for demanding control, instrumentation, and safety-critical systems. Efficiencies reach up to 64% with a working temperature range of -40°C to +75°C.
TRACO POWER THI31211 High Isolation DC/DC Converter Specifications:
- Isolation Voltage: 4000 VACrms, rated for 300 Vrms working
- Input Voltage Range: 5 VDC, 12 VDC, 24 VDC
- Output Currents: 600 mA at 5 V, 250 mA at 12 V, 200 mA at 15 V
- Efficiency: up to 64%
- Operating Temp Range: -40°C to +75°C
- Short Circuit Protection: Automatic recovery
- Input Filter: Pi-Filter
- Ripple and Noise: 50 mVpk-pk (20 MHz bandwidth)
- Leakage Current: <2 pA at 240VAC
- Isolation Capacitance: 220 pF (each output), Input/Output 20 pF
- Humidity: Up to 95% relative
- Dimensions: Encapsulated in DIP-24 package, weight approx 12.4 g
- Soldering Temperature: Max 260°C /10 sec
- Compliance: IEC/EN 60601-1, IEC 60950-1, RoHS
Buy the Buy Traco Power THI 3 Series Part Number THI31211 Online
Purchase the Traco Power high isolation DC/DC converter from the THI 3 series online today. Engineered for medical safety and industrial control applications, it offers reinforced insulation, low leakage current, and efficiency up to 64%. Ideal for healthcare devices and safety-critical systems, this fully regulated 5-24VDC converter provides reliable performance across a temperature range of -40°C to +75°C. Ensure compliance with IEC/EN standards and benefit from a compact DIP-24 package designed for durability and precision in demanding environments.
Get Traco Power THI 3 Series THI31211 today—designed for medical safety, reliability, and long-lasting performance in critical healthcare devices.
Frequently Asked Questions
Where can I buy TRACO POWER THI31211?
You can click on the BUY or RFQ button to purchase THI31211 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THI31211?
You can download the THI31211 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THI31211?
TRACO POWER
