TRACO POWER THM202413WI Medical Power Converter
The THM 20WI series is a reliable 20 Watt medical DC/DC converter with a compact 1.6 x 1-inch plastic case and ultra wide 4:1 input voltage range. Suitable for medical and demanding industrial applications, it offers reinforced isolation of 5000 VACrms, very low leakage current below 2.5 pA, and high efficiency up to 89%. Certified for IEC/EN/ES 60601-1 3rd edition with 2x MOPP, it operates reliably from -40°C to +80°C, meeting EMI standards IEC 60601-1-2 4th edition, and well-suited for transportation, control, measurement, or IGBT drivers.
TRACO POWER THM202413WI Medical Power Converter Specifications:
- Power Output: 20 W
- Input Voltage Range: 9 — 36 VDC / 48 VDC models available
- Output Voltage: 15 VDC ±10%
- Max Output Current: 1330 mA
- Efficiency: up to 89%
- Isolation Voltage: 5000 VACrms
- Leakage Current: < 2.5 pA
- Operating Temperature Range: -40°C to +80°C
- Dimensions: 1.6 x 1.0 x 0.4 inches (40.6 x 25.4 x 10 mm)
- Case Material: Non-conductive plastic
- Potting Material: Silicone (UL94 V-0 rated)
- Soldering Temperature: Max. 265°C / 10 seconds
- Certifications: IEC/EN/ES 60601-1 3rd edition, ISO 13485, IEC 60601-1-2
- Altitude Operation: Up to 5000 m
- MTBF: 1,712,000 hours
- Switching Frequency: 225-285 kHz
- Vibration & Shock Resistance: MIL-STD-810F
- No Load Input Current: 10 mA typical
- Start-up Voltage: 9 VDC or lower
- Protection: Overcurrent, overvoltage, thermal shutdown
- Remote On/Off: Optional with positive/negative logic
Buy the Traco Power Series THM 20WI Medical Power Supply: THM202413WI
Purchase the Traco Power THM 20WI series medical power converter online and ensure reliable operation in healthcare devices. This compact 20W device features reinforced isolation of 5000 VACrms, ultra-wide 4:1 input range, and efficiency up to 89%. Certified for IEC/EN/ES 60601-1 standards, it operates reliably from -40°C to +80°C, making it ideal for medical, transportation, industrial, and measurement applications. Benefit from low leakage current of less than 2.5 pA, robust construction, and a 5-year warranty by ordering now for peace of mind.
Get Traco Power THM202413WI today—built for medical precision, low leakage current, reinforced isolation, and long-term reliability.
Frequently Asked Questions
Where can I buy TRACO POWER THM202413WI?
You can click on the BUY or RFQ button to purchase THM202413WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM202413WI?
You can download the THM202413WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM202413WI?
TRACO POWER
