TRACO POWER TPP30148D medical power supply
The TPP 30-D Series is a compact, high-efficiency 30-watt medical power supply designed for professional healthcare applications. It features reinforced double I/O isolation, low leakage current below 75 pA, and meets IEC 60601-1 3rd edition standards for 2 x MOPP. With an operating temperature range from -40°C to +60°C, it supports altitudes up to 5000 meters and complies with EMC emission and immunity standards. Its robust construction ensures reliable operation in medical environments, offering up to 92% efficiency, low no-load power consumption, and a five-year warranty, making it ideal for medical equipment and BF applications.
TRACO POWER TPP30148D medical power supply Specifications:
- Power: 30 W
- Output Voltage: 48 VDC (43.2 - 528 VDC)
- Output Current: 630 mA
- Input Voltage: 85 - 264 VAC / 120 - 370 VDC
- Input Frequency: 47 — 63 Hz
- Efficiency: Up to 92%
- Operating Temperature Range: -40°C to +60°C, up to 85°C with load derating
- Protection Class: Class II with reinforced insulation
- Leakage Current: <75 pA
- Protection: Continuous short circuit, overvoltage 125-140% Vout
- Isolation Test Voltage: 5,000 VAC input to output
- Dimensions: 50 mm x 73.3 mm x 25.6 mm
- Mounting: Through-hole
- Certifications: IEC 60601-1, IEC 62368-1, UL 62368-1, RoHS, REACH
- Vibration & Shock: IEC 60068-2-6, IEC 60068-2-27
- Altitude Limit: 5,000 meters
- Operating at 47-63 Hz frequency
- Creepage/clearance: 8 mm min.
- Weight: 106 g
- Working Voltage: 272 VAC
- Insulation Resistance: 100 MOhm min. at 500 VDC
Buy the Traco Power TPP 30-D – Reliable Medical Power Supply for Industrial Applications
Purchase the Traco Power TPP 30-D power supply online today—designed for medical applications requiring high efficiency, reinforced insulation, and low leakage current. Its compact size, wide temperature range, and robust safety certifications make it ideal for healthcare devices and BF applications. Enjoy fast delivery, secure checkout, and expert support. Whether upgrading existing equipment or developing new medical devices, the TPP 30-D ensures reliable operation, long-term durability, and compliance with strict medical safety standards. Order now for peace of mind and superior performance.
Get Traco Power TPP 30-D today—built for medical and industrial reliability in critical applications.
Frequently Asked Questions
Where can I buy TRACO POWER TPP30148D?
You can click on the BUY or RFQ button to purchase TPP30148D from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP30148D?
You can download the TPP30148D datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP30148D?
TRACO POWER
