TRACO POWER THL104810WI Industrial Power Converter
The THL 10-4810WI from TracoPower is a 10W DC-DC converter belonging to the THL 10WI series. It features a compact 1" x 1" metal case with an isolated baseplate, making it suitable for space-constrained industrial and communication applications. The converter operates with an input voltage range of 18V to 75V DC (nominally 48V DC) and provides a stable 3.3V DC output with a maximum current of 2200mA. It boasts an efficiency of approximately 85%, an ultra-wide 4:1 input voltage ratio, and complies with safety standards UL/cUL 60950-1 and IEC/EN 60950-1. The device includes features such as remote On/Off control, short circuit protection, overvoltage protection, and an input filter that meets EN 55022 Class A without external components. It supports operating temperatures up to +75°C or +85°C with an optional heatsink. The converter offers an input/output isolation voltage of 1500V DC, an isolation capacitance up to 1200pF, and an isolation resistance exceeding 1000 MΩ at 500V DC. Typical applications include instrumentation, distributed power supplies in communication systems, and industrial electronics.
TRACO POWER THL104810WI Industrial Power Converter Specifications:
- Power: 10W
- Input Voltage Range: 18V to 75V DC
- Output Voltage: 3.3V DC
- Output Current Max: 2200mA
- Efficiency: approximately 85%
- Isolation Voltage: 1500V DC
- Isolation Capacitance: up to 1200pF
- Isolation Resistance: >1000 MΩ at 500V DC
- Operating Temperature Range: -40°C to +75°C, up to +85°C with heatsink
- Protection: Short circuit, overvoltage, remote On/Off
- Safety Standards: UL/cUL 60950-1, IEC/EN 60950-1
- Dimensions: 1" x 1" x 0.4" (approximate)
- Input Filter: Meets EN 55022 Class A without external components
- Input/Output: Galvanic Isolation
- Construction: Metal case with non-conductive potting material
- Maximum case temperature: +100°C
- Soldering Temp: Max +260°C for 10s
Buy the Buy TracoPower THL 10-4810WI Part Number THL104810WI Online
Order the TracoPower THL 10-4810WI online today to benefit from a compact, efficient, and safety-compliant 10W DC-DC converter. Its isolated design, wide input range, and remote On/Off feature make it ideal for industrial electronics, instrumentation, and distributed power solutions in communication systems. With UL/cUL safety approval and high input/output isolation, this converter guarantees reliable operation in demanding environments. Enjoy fast delivery, competitive pricing, and the convenience of purchasing high-quality power modules directly from our secure online store for all your industrial and electronic project needs.
Buy TracoPower THL 10-4810WI now and ensure reliable industrial power conversion with high efficiency and extensive safety features.
Frequently Asked Questions
Where can I buy TRACO POWER THL104810WI?
You can click on the BUY or RFQ button to purchase THL104810WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL104810WI?
You can download the THL104810WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL104810WI?
TRACO POWER
