TRACO POWER TEN32415N DC-DC Converter
The TEN 3-2415N from TracoPower is a 3W single-output DC-DC converter housed in a 24-pin DIP package. It is designed as a drop-in replacement for the widely used TEN 3 series, offering a modernized design that reduces cost without compromising reliability or functionality. This converter features a wide 2:1 input voltage range (18V to 36V) and includes an input filter to meet EN 55022, Class A, and FCC Level A standards without external components. It provides enhanced electromagnetic compatibility (EMC) immunity, an extended operating temperature range from -40°C to +85°C, and continuous, automatic recovery short-circuit protection, with no minimum load required. The device supports high efficiency (approximately 84%) and has an MTBF greater than 1 million hours for high reliability. It is compliant with UL, IEC, and CSA standards, featuring robust ESD protection (Air ±8KV, Contact ±6KV), high isolation resistance over 1000 MΩ at 500VDC, and I/O isolation of 1500VDC. Its compact dimensions are 20.3mm x 10.2mm x 31.8mm. The converter accepts a start-up voltage of 18VDC or lower, with a maximum surge voltage of 50V for 1 second. It is suitable for power management and industrial applications requiring dependable and efficient power conversion.
TRACO POWER TEN32415N DC-DC Converter Specifications:
- Power Output: 3W
- Input Voltage Range: 18V to 36V
- Output Voltage: 15 VDC
- Output Current: 200 mA
- Efficiency: Approximately 84%
- Isolation Voltage (Input/Output): 1500 VDC
- Isolation Resistance: >1,000 MΩ at 500 VDC
- Start-up Voltage: 18 VDC or lower
- Surge Voltage (1 sec): 50 V max.
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -55°C to +125°C
- Dimensions: 20.3 mm x 10.2 mm x 31.8 mm
- Weight: 12.8 g
- Compliance: UL 60950-1, IEC 60950-1, CSA
- EMC Immunity: EN 61000-4-2,4,5,6, EN 55024
- Ripple and noise: 70 mVpk-pk (20 MHz bandwidth)
- Short circuit protection: Continuous, auto recovery
- Environmental: RoHS, Reach compliant
- Soldering Temperature: Max. 260°C for 10 sec.
Buy the Buy TracoPower TEN 3-2415N Part Number TEN32415N Online
Secure your TracoPower TEN 3-2415N today and enhance your power management systems with a high-efficiency, robust DC-DC converter. Its extended temperature range, high isolation, and UL/IEC/CSA approvals make it ideal for industrial applications. With a compact design measuring only 20.3mm x 10.2mm x 31.8mm, this 3W converter offers reliable performance, automatic short-circuit recovery, and excellent EMC immunity. Purchase online now to ensure your power solutions are cost-effective, durable, and compliant with international safety standards for demanding environments.
Order your TracoPower SeriesTEN32415N 3W power converter today and enjoy reliable, efficient power supply for industrial or power management applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32415N?
You can click on the BUY or RFQ button to purchase TEN32415N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32415N?
You can download the TEN32415N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32415N?
TRACO POWER
