TRACO POWER THM64823 Medical Power Converter
The THM 6 Series is a range of medical-grade 6 Watt DC/DC converters designed for reliable power supply in medical equipment and demanding applications like transportation and measurement. These converters feature 2:1 wide input voltage range, reinforced insulation of 5000 VACrms, and low leakage current below 2A. Compliant with IEC/EN/ES standards including IEC 60601-1 3rd edition for 2 MOPP, they operate efficiently up to 89% and within -40°C to +90°C. They also meet EMC requirements and are built with high-quality components, ensuring safety, durability, and consistent performance in harsh environments.
TRACO POWER THM64823 Medical Power Converter Specifications:
- Input voltage range: 4.5V to 36VDC, 2:1 wide input range
- Output voltages: 3.3V, 5V, 12V, 15V, 24V, 36V, +Vout models as specified
- Max output current: from 250mA up to 4200mA depending on model
- Efficiency: up to 89%, typical at 86-89%
- Isolation voltage: 5000 VACrms, rated for 250 VACrms working voltage
- Leakage current: less than 2A at 240VAC
- Operating temperature: -40°C to +90°C without derating, temperature coefficient approx. 0.02%/K
- Start-up voltage: 4.5VDC to 36VDC depending on model
- Under voltage shutdown: from 4VDC to 33VDC
- Ripple and noise: 30-60 mVp-p depending on load
- Protection: Overload at 150%, auto recovery; short circuit, over voltage protections
- Dimensions: Small DIP-24 plastic case, approx. 23.5 mm x 20.5 mm x 12 mm
- Compliance: IEC/EN/ES 60601-1 3rd edition, EMC EN55032 class A, IEC 60601-1-2 4th edition
- Certifications: ISO 13485, IEC/EN/ES 60601-1, UL recognition
Buy the Traco Power THM 6 Series – Reliable Medical DC/DC Converters for Industrial Applications
Purchase the Traco Power THM 6 Series online today and benefit from high efficiency, reinforced insulation, and proven medical-grade safety features. These 6 Watt DC/DC converters are ideal for demanding applications like medical equipment, transportation, and measurement systems. With wide input voltage range, low leakage current, and robust protection mechanisms, they ensure reliable performance even in harsh environments. Highly compliant with IEC/EN/ES standards, these converters come in compact DIP-24 cases for easy integration and long-term durability. Buy now for trusted quality and quick delivery.
Get Traco Power THM 6 Series today—built for medical-grade reliability and demanding industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER THM64823?
You can click on the BUY or RFQ button to purchase THM64823 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM64823?
You can download the THM64823 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM64823?
TRACO POWER
