TRACO POWER TMPW50124 Power Supply Module
The TMPW 50 series is a compact 50 Watt AC/DC power supply designed for industrial and household applications. It features a wide input voltage range of 90-305 VAC, high efficiency up to 89%, and reinforced insulation with an isolation voltage of 4000 VAC. Its rugged plastic case allows operation from -40°C to +70°C, with safety certifications including IEC/EN/UL 62368-1 and EN 60335-1. The device includes an internal EMI filter, low no-load power consumption, and protection for overvoltage and short circuits, making it reliable for demanding environments.
TRACO POWER TMPW50124 Power Supply Module Specifications:
- Input Voltage: 90 - 305 VAC, 100 - 250 VDC
- Input Frequency: 47 - 63 Hz (designed for 47 - 440 Hz)
- Output Power: 50 W
- Output Voltage Options: 15 VDC, 24 VDC, 42 VDC
- Output Current: 3.33 A, 2.083 A, 4.167 A respectively
- Efficiency: up to 89%
- Isolation Voltage: 4000 VAC
- Operating Temperature Range: -40°C to +70°C
- Cooling: Natural convection
- Dimensions: 2.92 x 1.85 inches
- Housing Material: UL 94 V-0 rated plastic
- Protection Class: II (reinforced insulation)
- Short Circuit Protection: Continuous with automatic recovery
- Overvoltage Protection: 105-145% of Vout nominal
- Vibration Resistance: IEC 60068-2-6
- Environmental Compliance: RoHS, Reach
- Weight: 158 g
Buy the Traco Power TMPW 50 – Reliable Power Supply for Industrial Applications
Experience the reliability and efficiency of the Traco Power TMPW 50 power supply, designed for industrial and household applications. With a compact size, wide input voltage range, and high efficiency up to 89%, this power module offers reinforced insulation and robust safety features. Suitable for various demanding environments, it supports operational temperatures from -40°C to +70°C, includes an internal EMI filter, and ensures safety compliance with IEC/EN/UL standards. Purchase online now for consistent performance and peace of mind.
Get Traco Power TMPW 50 today—built for precision, high efficiency, and long-lasting durability in demanding environments.
Frequently Asked Questions
Where can I buy TRACO POWER TMPW50124?
You can click on the BUY or RFQ button to purchase TMPW50124 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMPW50124?
You can download the TMPW50124 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMPW50124?
TRACO POWER
