TRACO POWER THN151215N DC/DC Converter
The THN 15N series is a high-performance 15 Watt DC/DC converter in a compact 1” x 1” x 0.4” metal package, featuring a 2:1 input voltage range of 9-36 VDC, up to 91% efficiency, and operating from -40°C to +70°C without derating. It includes an internal EN 55032 class A filter, overload and short circuit protection, remote On/Off, and Trim functions. Suitable for space-constrained applications in industrial electronics, communication, and instrumentation, it complies with UL 62368-1 standards for safety and EMI regulations.
TRACO POWER THN151215N DC/DC Converter Specifications:
- Power Output: 15 Watt
- Input Voltage Range: 9-36 VDC, wide 2:1 ratio
- Efficiency: Up to 91%
- Operating Temperature: -40°C to +70°C without derating
- Isolation Voltage: 1600 VDC
- Dimensions: 1" x 1" x 0.4" metal package
- Remote On/Off: On open/3-15 VDC, Off short or 0-1.2 VDC
- Protection: Overload, overvoltage, short circuit
- Ripple & Noise: 75 mVp-p (5 Vout models), 125 mVp-p (12 Vout models)
- Start-up Time: Max 40 ms
- MTBF: 1,670,000 hours
- Certification: UL 62368-1, EN 55032 Class A EMI
Buy the Traco Power Series THN 15N 15 Watt DC/DC Converter: THN151215N
Secure your Traco Power Series THN 15N 15 Watt DC/DC converter online now to ensure efficient and stable power supply for your industrial, communication, or instrumentation projects. These reliable, compact power modules feature a wide input voltage range, high efficiency up to 91%, and operate over -40°C to +70°C without derating. With built-in protections, EMI filters, and remote On/Off functionality, they are ideal for space-constrained applications. Purchase now to benefit from quick delivery and trusted quality!
Order your Traco Power Series THN 15N 15 Watt DC/DC Converter today and enhance your projects with reliable, high-efficiency power solutions.
