TRACO POWER THN154812N DC/DC Converter
The THN 15N Series 15 Watt DC/DC converters feature compact metal packaging measuring 1 inch by 1 inch by 0.4 inches, offering high efficiency up to 91%. They support a wide 2:1 input voltage range from 9V to 75V DC, with various output voltages including 3.3V, 5V, 12V, 15V, and 24V. Designed for versatile applications like mobile equipment, instrumentation, communication, and industrial electronics, these converters have an operating temperature from -40°C to +70°C without derating, internal filters, overload and short circuit protection, remote On/Off, and a 3-year warranty.
TRACO POWER THN154812N DC/DC Converter Specifications:
- Power Rating: 15 Watt
- Input Voltage Range: 9-75 VDC (wide 2:1 ratio)
- Output Voltages: 3.3V, 5V, 12V, 15V, 24V and adjustable options (+10% to +20%)
- Efficiency: up to 91%
- Operating Temperature: -40°C to +70°C without derating
- Isolation Voltage: 1600 VDC (input to output)
- Protection: Overload, overvoltage, short circuit
- Remote On/Off: Open/3-15VDC on, Short/0-1.2 VDC off
- Ripple & Noise: 75 mVp-p (5V), 4100 mVp-p (12V), 125 mVp-p (15V)
- MTBF: 1,670,000 hours
- Switching Frequency: 220-270 kHz
- Case Material: Copper, Potting: Silicone
- Size: 1” x 1” x 0.4”
- Humidity: 5-95% non condensing
- Certifications: IEC/EN/UL 62368-1
- Isolation Resistance: ≥1 GOhm
- Derating: As per model, refer to datasheet
Buy the Traco Power Series THN: 15 Watt DC/DC Converter
Purchase the Traco Power THN 15N Series DC/DC converter online today for a compact, high-efficiency power solution suited for industrial electronics, communication equipment, and instrumentation. With a robust 15W output, wide 9-75V input range, and low no-load power consumption, this converter provides reliable and isolated outputs. Features include overload, overvoltage, and short circuit protection, remote On/Off control, and compliance with IEC 62368-1 safety standards. Perfect for applications with space constraints and demanding operational conditions.
Get Traco Power THN 15N today—designed for high efficiency, wide input voltage range, and reliable industrial performance.
Frequently Asked Questions
Where can I buy TRACO POWER THN154812N?
You can click on the BUY or RFQ button to purchase THN154812N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN154812N?
You can download the THN154812N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN154812N?
TRACO POWER
