TRACO POWER THN302411 DC/DC Converter
The THN 30 Series is a high-performance 30 Watt DC/DC converter with a compact 1.0” x 1.0” x 0.4” metal case, designed for efficient power conversion in space-constrained applications. It features an ultra-wide 2:1 input voltage range, high efficiency up to 92%, and operates reliably from -40°C to +85°C with a heatsink. The device offers low no-load input current, remote On/Off control, and robust isolation of 1500 VDC. Suitable for industrial, communication, and mobile systems, it ensures stable, precise output voltages under varying loads and environmental conditions.
TRACO POWER THN302411 DC/DC Converter Specifications:
- Power Output: 30W
- Input Voltage Range: 9-36 VDC with wide 2:1 ratio
- Efficient: Up to 92% at full load
- Operating Temperature: -40°C to +85°C with heatsink, -40°C to +80°C without
- Dimensions: 1.0” x 1.0” x 0.4” (25.4 x 25.4 x 10.16 mm)
- Isolation Voltage: 1500 VDC input/output
- Output Voltage: Adjustable, with models for 3.3V, 5V, 9V-18V, 12V, 15V, 24V
- Output Current: Up to 7000 mA depending on model
- Efficiency Range: 86-92% depending on the specific model
- Remote On/Off: Yes, 3.0 to 15 VDC control
- Input Current at No Load: 8–12 mA depending on input voltage
- Protection: Over temperature, overvoltage, short circuit with hiccup mode
- Safety & Certification: UL 60950-1, IEC/EN 60950-1, RoHS compliant
- Environmental: Non-condensing humidity up to 95%, natural convection thermal impedance 15.0°C/W
Buy the TracoPower Series THN 30 Power: THN 30-2412
Discover the compact and high-efficiency TracoPower Series THN 30-2412 DC/DC converter, designed for demanding electronic projects. With a robust 30W output, wide input voltage range, and operating temperature up to 85°C, it ensures stable, reliable power in space-constrained applications. Its high efficiency surpasses 89%, reducing energy loss. The device features isolation of 1500 VDC, remote On/Off control, and built-in protections against overtemperature and overvoltage. Ideal for industrial, communication, and portable systems, buy online today for dependable power delivery in your next project.
Order your TracoPower Series THN 30-2412 high-performance 30W converter today and ensure reliable power supply for your industrial and communication systems.
Frequently Asked Questions
Where can I buy TRACO POWER THN302411?
You can click on the BUY or RFQ button to purchase THN302411 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN302411?
You can download the THN302411 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN302411?
TRACO POWER
