TRACO POWER TMA1515D Industrial Power Converter
The TMA series are compact, high-efficiency 1 W DC/DC converters in a Single-in-Line package, ideal for space-critical applications. They offer single and dual output models with 1000 VDC isolation, operating over -40°C to +85°C. Features include industry-standard pinouts, RoHS compliance, and a robust 3-year warranty. These converters are suitable for board-level power distribution, providing up to 81% efficiency. Their SMD technology ensures low-cost, high-performance power solutions for industrial and embedded systems requiring reliable, isolated power conversions.
TRACO POWER TMA1515D Industrial Power Converter Specifications:
- Package Type: Single-in-line (SIP)
- Power Output: 1 Watt
- Input Voltage Range: 5 VDC, 12 VDC, 15 VDC, 24 VDC (varies by model)
- Output Voltage: 5 VDC, 12 VDC, 15 VDC (single and dual models)
- Output Current: 200 mA (5 V models), 80-100 mA (others)
- Isolation Voltage: 1000 VDC
- Efficiency: Up to 81%
- Operating Temperature Range: -40°C to +85°C
- RoHS Compliant, Lead-free design
- Dimensions: Compact board-level footprint, typical size approximately 1.2 cm²
- Soldering Temperature: Max 265°C for 10 sec
- Ripple and Noise: 100 mVp-p (20 MHz bandwidth)
- Switching Frequency: 100 kHz
- Reliability MTBF: >2,000,000 hours
- Case Material: Non-conductive UL 94V-0 rated plastic
Buy the TracoPower Series TMA DC/DC Converter: TMA1515D
Enhance your electronic systems with the TracoPower TMA1515D isolated 1 W DC/DC converter, featuring high efficiency of up to 81%, wide temperature operation from -40°C to +85°C, and industry-standard pinouts. Its compact SIP package saves board space, making it ideal for space-critical applications. RoHS compliant and lead-free, it offers reliable power conversion for industrial control, automation, and embedded systems. Order online now for a durable, high-performance solution designed to meet demanding technical requirements.
Get TracoPower TMA1515D today—built for precision and long-lasting durability in industrial and embedded power applications.
Frequently Asked Questions
Where can I buy TRACO POWER TMA1515D?
You can click on the BUY or RFQ button to purchase TMA1515D from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMA1515D?
You can download the TMA1515D datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMA1515D?
TRACO POWER
