TRACO POWER TBL030124 Industrial Power Supply
The TBL series industrial power supplies are compact, low-profile units designed for building and factory automation. With an ultra-compact case depth of 55mm, they fit into standard wall-mounted control panels. These UL 508 and UL 1310 class II rated power supplies offer adjustable output voltage, operate across -25°C to +70°C, and feature easy DIN-rail mounting or wall brackets. Suitable for worldwide applications, they provide high efficiency, short circuit, overload, and overvoltage protections, and are compliant with EMC and safety standards, ensuring reliable, long-lasting operation.
TRACO POWER TBL030124 Industrial Power Supply Specifications:
- Power Range: 15 to 150 W
- Input Voltage: 85 - 264 VAC, 47 - 63 Hz; 120 - 373 VDC
- Output Power: 12 W to 150 W depending on model
- Output Voltage: 5 VDC to 28 VDC adjustable
- Output Current: 24A at 5 V, 6.25 A at 24 V
- Efficiency: Up to 87%
- Operating Temperature Range: -25°C to +70°C
- Protection: Short circuit, overload, overvoltage
- Certifications: UL 508, UL 1310, CE, CB, RoHS
- Mounting: DIN-rail, wall bracket included
- Dimensions: Width varies from 26.3mm to 175mm depending on model
- Enclosure Material: UL 94V-0 rated plastic
- Ingress Protection: IP20
- Vibration & Shock Resistance: IEC compliant, 10-55Hz sine sweep, 15g shock
Buy the Power Series TBL Industrial Power Supplies: TBL030124
Purchase the Traco Power TBL030124 online now for a compact, high-efficiency industrial power supply perfect for automation systems and building control panels. Designed for reliable long-term operation, this unit offers adjustable voltage, UL and CE safety approvals, and easy DIN-rail mounting. With a versatile input range, high efficiency, and protections against short circuit, overload, and overvoltage, it ensures consistent power delivery in demanding environments. Order today for a trusted solution that meets global safety and EMC standards, enhancing your automation projects with ease.
Get Traco Power TBL030124 today—compact and reliable power supply ideal for building automation and industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER TBL030124?
You can click on the BUY or RFQ button to purchase TBL030124 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TBL030124?
You can download the TBL030124 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TBL030124?
TRACO POWER
