TRACO POWER TMDC604818 DC-DC Converter Module
The Transcopower TMDC 60-4818 is a 60W high-performance, single-output DC-DC converter module housed in a fully encapsulated, low-profile plastic case. It is designed for chassis or PCB mounting with optional screw terminal connections. Features include a wide input voltage range from 18V to 75V DC, a 48V DC output at up to 1250mA, and a high efficiency of 91%. Operating at a switching frequency of 285kHz, it offers tight regulation, hiccup mode for short-circuit recovery, and does not require a minimum load. It provides remote On/Off, overload, and short-circuit protection, with compliance to EN 55024 and IEC 61000-4 standards. The device ensures reliable power conversion in industrial environments, with an operating temperature of -40°C to 85°C, UL and IEC certifications, and optional DIN-rail mounting.
TRACO POWER TMDC604818 DC-DC Converter Module Specifications:
- Input Voltage Range: 18V to 75V DC
- Output Voltage: 48V DC
- Output Current Max: 1250mA
- Efficiency: 91%
- Maximum Power: 60W
- Isolation Voltage: 2500 VDC (input/output, 60 sec.)
- Operating Temperature: -40°C to +85°C
- Switching Frequency: 285 kHz typ.
- Ripple & Noise (20 MHz BW): 200 mVpk-pk
- Protections: Over voltage (120%), Short circuit (hiccup mode), Overload
- Standards: UL/cUL 60950-1, IEC 60950-1, EN 55024, EN 61000-4-2/3/4/5/6/8
- Case Material: Plastic (UL 94V-0)
- Weight: 300 g
- Dimensions: As per detailed diagram, W: 67.8 mm, L: 126.7 mm
- Optional DIN-rail mount adapter available
Buy the TracoPower TMDC 60-4818 – Reliable DC Power Supply for Industrial Applications
Purchase the TracoPower TMDC 60-4818 online today and secure a high-efficiency, reliable DC power solution designed for demanding industrial environments. With wide input voltage compatibility from 18V to 75V DC, this 60W module features a 48V output at 1250mA, high efficiency of 91%, and comprehensive protections including short-circuit and over-voltage. Its compact encapsulated design with optional DIN-rail mounting makes it suitable for various industrial applications. Enjoy fast delivery and technical support when you buy online, ensuring your systems operate smoothly and reliably.
Order your Tracopower SeriesTMDC 60-4818 today and ensure dependable power for your industrial projects.
