TRACO POWER TENHS1 DC/DC Converter Module
The TEN 20WIN series consists of high-performance 20W DC/DC converters in a compact 2" x 1" metal package, offering an ultra wide 4:1 input voltage range with up to 88% efficiency. Designed for industrial and communication applications, they feature remote On/Off, output voltage adjustments, and robust protection features including over-voltage and short-circuit protection. Operating over a temperature range of -40°C to +85°C, these certified, RoHS-compliant modules are ideal for battery-powered and distributed power systems requiring isolated, regulated voltages with high reliability and minimal size.
TRACO POWER TENHS1 DC/DC Converter Module Specifications:
- Power: 20W
- Input Voltage Range: 9-36 VDC, 18-75 VDC, 24 VDC Nominal, 48 VDC Nominal
- Input Current at Full Load: 24V Models: 1000 mA; 48V Models: 500 mA
- Efficiency: up to 89%
- Output Voltage Adjustment: +10% by external resistor
- Output Power: 3.3V, 5V, 12V, 15V, 24V, 48V options
- Maximum Output Current: 5,500 mA for 3.3V, 4,000 mA for 5V, 1,670 mA for 12V, 1,330 mA for 15V, 2,000 mA for 5V (some models)
- Isolation Voltage: 1500 VDC (Input/Output)
- Temperature Range: -40°C to +85°C operating, -55°C to +125°C storage
- Protection Features: Over-voltage, short-circuit, over-current, thermal shutdown
- Dimensions: 2" x 1" x 0.4" (52 mm x 26 mm x 10 mm)
- Standards & Certifications: UL 60950-1, RoHS, EN/IEC 60950-1
- Environmental: Non-condensing humidity up to 95%, MTBF over 1.8 million hours
- Construction: Metal case, insulated baseplate, optional heatsink available
- Switching Frequency: 400 kHz typ.
- Isolation Resistance: >1 GΩ
Buy the Buy Traco Power TEN 20WIN Series DC/DC Converter Part Number TENHS1 Online
Enhance your power systems with the compact and high-efficiency DC/DC converter from Traco Power. The TEN 20WIN series offers ultra wide input ranges, operating from -40°C to +85°C, ensuring dependable performance in industrial and communication settings. Equipped with remote On/Off, output voltage trimming, and robust protection features, this 20W module guarantees safety and reliability. Its industry-standard footprint and optional heatsink make installation simple, making it an ideal choice for regulated power in distributed architectures and battery-powered equipment, available for online purchase now.
Order your Traco Power TEN 20WIN series TENHS1 DC/DC converter today and ensure your systems benefit from reliable, high-efficiency power solutions.
