TRACO POWER TMPW10105 DC Power Supply
The TMPW 10 is a compact 10 Watt AC/DC power supply designed for industrial and household applications. It features a wide input voltage range of 90-305 VAC, high efficiency up to 86%, and a reinforced insulation with protection class II. The power supply offers an output voltage accuracy of ±2%, low no-load power consumption below 0.1W, and a high-temperature operating range of -40°C to +70°C. It is certified according to IEC, UL, and EN standards, includes an internal EMI filter, and provides safety features like overvoltage and short circuit protection for reliable performance in demanding environments.
TRACO POWER TMPW10105 DC Power Supply Specifications:
- Power Output: 10 Watts
- Input Voltage Range: 90-305 VAC, 100-250 VDC
- Input Frequency: 47-63 Hz (designed for 47-440 Hz)
- Output Voltage Accuracy: ±2%
- Efficiency: up to 86%
- Operating Temperature: -40°C to +70°C
- Isolation Voltage: 47000 VAC (input to chassis), 4000 VAC (input to output)
- Protection Class: II (reinforced insulation)
- Ripple and Noise: 60-150 mVp-p depending on model
- Dimensions: 1.46" x 1.08" x 0.9"
- Ingress Protection: Encapsulated plastic case
- Safety Certifications: IEC 62368-1, UL 62368-1, EN 60335-1
- Power Consumption No load: < 0.1W; Inrush Current: 60A at 230VAC
- Load Regulation: 1-2%
Buy the Buy Traco Power AC/DC Power Supply Part Number TMPW10105 Online
Purchase the Traco Power TMPW 10 series online today and benefit from a compact 10 Watt power supply with wide input voltage, high efficiency up to 86%, reinforced insulation, and comprehensive safety certifications. Ideal for industrial, household, and building technology applications, this power supply offers excellent regulation, low standby power consumption, and internal EMI filters to save space and enhance performance. Order now for trusted quality and quick delivery to ensure your projects remain reliable and compliant with international safety standards.
Buy Traco Power TMPW 10 series power supply now and experience reliable performance with high efficiency and safety standards for industrial and home applications.
Frequently Asked Questions
Where can I buy TRACO POWER TMPW10105?
You can click on the BUY or RFQ button to purchase TMPW10105 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMPW10105?
You can download the TMPW10105 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMPW10105?
TRACO POWER
