TRACO POWER TMDC064825 DC/DC Converter
The TMDC 06 series is a compact, fully encapsulated 6-watt DC/DC converter designed for harsh industrial environments. It features ultra-wide input voltage ranges of 9-36 VDC and 18-75 VDC, with high efficiency up to 85%. The modules provide 3000 VDC isolation, incorporate integrated filters for EMC compliance (EN 55032 and EN 55035), and operate without derating from -40°C to +80°C. Certified under UL 62368-1, they include remote On/Off, DC-OK indicators, overload, undervoltage, and short circuit protection, making them ideal for reliable industrial power applications.
TRACO POWER TMDC064825 DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC with 4:1 wide input ratio
- Output Power: 6 Watts
- Isolation Voltage: 3000 VDC
- Efficiency: up to 85%
- Operating Temperature: -40°C to +80°C without derating
- Mechanical Dimensions: 2.09'' x 1.34'' x 1.04'' (53 x 34 x 26.5 mm)
- Protection Features: Overload, undervoltage, short circuit
- EMC Compliance: EN 55032 class A, EN 55035 immunity
- Safety Certifications: UL 62368-1, IEC 62368-1
- Remote On/Off and DC-OK indicator
- Housing Material: UL 94V-0 rated plastic
- Connection: Screw terminal
- Signal Isolation: 3000 VDC, 17000 MOhm resistance
- Operating Humidity: Up to 95% non-condensing
- Switching Frequency: 370 kHz
- Power Derating: 4%/K above 80°C
Buy the Traco Series TMDC DC/DC Converter: TMDC 06-825
Purchase the Traco Series TMDC 06-825 DC/DC converter online today. This highly efficient, rugged power module offers wide input ranges, 3000V isolation, and certified safety standards. Its compact design and industrial-grade EMC immunity make it ideal for demanding applications requiring reliable power conversion. Equipped with remote On/Off and DC-OK indicator, it ensures seamless integration into complex systems. Order now to enjoy quick delivery and support for your industrial power needs. Trust Traco for quality and performance.
Buy Traco Series TMDC 06-825 now and experience unmatched reliability and industrial performance in harsh environments.
Frequently Asked Questions
Where can I buy TRACO POWER TMDC064825?
You can click on the BUY or RFQ button to purchase TMDC064825 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMDC064825?
You can download the TMDC064825 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMDC064825?
TRACO POWER
