TRACO POWER TMH0512S DC/DC Converter
The TMH series are ultra-compact, isolated 2 Watt DC/DC converters designed in a single-in-line package that requires only 1.5 cm² of board space. These fully SMD-designed modules offer high efficiency up to 83%, with optional single or dual output configurations and 1/0 galvanic isolation of 11,000 VDC. Suitable for space-critical applications, they feature industry-standard pinouts, are RoHS compliant, and undergo 8-hour burn-in testing to ensure reliability. They are ideal for board-level power distribution in industrial and electronics projects.
TRACO POWER TMH0512S DC/DC Converter Specifications:
- Input voltage: 5 VDC, 12 VDC, 24 VDC models with Surge voltages of 9 V, 18 V, 30 V max.
- Output power: 2 Watt with single or dual outputs.
- Efficiency: up to 83% across models.
- Isolation voltage: 11,000 VDC for 60 seconds.
- Input current: 50 mA no load (5 V), 20 mA (12 V), 10 mA (24 V); full load: 510 mA (5 V), 200 mA (12 V), 100 mA (24 V).
- Operating temperature: -40°C to +85°C, case max 90°C.
- Dimensions: 19.5 mm x 10.25 mm x 12.0 mm, weight: 27 g.
- Package: Non-conductive black plastic, UL 94 V-0 rated.
- Soldering temperature: Max +265°C for 10 seconds.
- Ripple & noise: 75 mV pk-pk (5 V), 150 mV pk-pk (12/24 V).
- Isolation capacitance: 80 pF, resistance: >1000 MΩ.
- Certification: RoHS compliant, UL, CE markings.
- Switching frequency: approximately 80 kHz.
- Reliability: MTBF over 2 million hours.
Buy the TracoPower TMH0512S – Reliable DC/DC Converter for Industrial Applications
Get your Traco Power TMH0512S 2 Watt isolated DC/DC converter online today. Perfect for space-constrained industrial projects, this highly efficient module offers 11,000 VDC isolation and a compact design. Engineered with industry-standard pinouts and RoHS compliance, it guarantees reliable power conversion with up to 83% efficiency. Suitable for board-level power distribution, it's designed to meet demanding industrial environments and ensure long-term performance. Purchase now to benefit from fast shipping and secure online ordering for your electronics needs.
Order your Traco Power Series TMH0512S 2 Watt isolated DC/DC converter today and enhance your industrial power solutions with dependable performance.
Frequently Asked Questions
Where can I buy TRACO POWER TMH0512S?
You can click on the BUY or RFQ button to purchase TMH0512S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMH0512S?
You can download the TMH0512S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMH0512S?
TRACO POWER
