TRACO POWER TEN62413N DC-DC Converter

The TEN 6-2413N from TracoPower is a high-performance, single-output 6W DC-DC converter housed in a 24-pin DIP package. Designed for optimal cost-to-performance ratio, it features overload protection, internal filtering compliant with EN55022 Class A standards, no minimum load requirement, and high efficiency. The converter is a drop-in replacement suitable for many cost-sensitive applications, thanks to its familiar DIP-24 package. It offers a wide 2:1 input voltage range and tight output voltage regulation. The device includes continuous, automatic recovery short-circuit protection and features a UL 94V-0 rated non-conductive plastic case with UL 94V-0 rated epoxy potting. Typical applications include distributed power architectures, workstations, computer equipment, and communication devices. It accepts an input voltage range from 18VDC to 36VDC, with an input current of 20mA at no load, and provides an output of 15VDC at a maximum current of 400mA. The converter operates with an efficiency of 84%, has an I/O isolation of 1500VDC, and a voltage set accuracy within ±2%. It switches at 330kHz, is approved under UL/cUL 60950-1 and IEC/EN 60950-1 standards, and can start-up at 18VDC or lower with a maximum surge voltage of 50V for 1 second. The I/O isolation resistance exceeds 1000 MΩ at 500VDC, with an I/O capacitance of 1000pF. Its dimensions are 20.3mm x 10.2mm x 31.8mm (W x H x D), and it operates reliably within an ambient temperature range of -40°C to +85°C.

View TEN62413NDatasheet [pdf]

Buy the TracoPower Series TEN 6N DC-DC Converter: TEN62413N

Purchase the TracoPower TEN62413N DC-DC converter online today for reliable, high-efficiency power supply solutions. This 6W, single-output module offers wide input voltage range from 18V to 36V, with a maximum output of 15V and 400mA current. Designed with a UL 94V-0 plastic case, it features overvoltage, overload, and short circuit protection, plus automatic recovery. Suitable for distributed power architectures, communication devices, and computer equipment, it provides excellent electrical isolation, meets EN 55022 Class A standards, and operates reliably from -40°C to +85°C. Order now for quick, secure delivery.

Get TracoPower TEN62413N today—built for precision and long-lasting durability in your power conversion needs.
