TRACO POWER TEN31222 Industrial Power Converter
The POWER TEN series DC/DC converters provide reliable 3W power solutions for industrial applications, featuring high efficiency up to 84%, wide input ranges, and full SMD design. They ensure excellent noise filtering, possess short circuit protection, and operate reliably from -40°C to 85°C. These converters meet EN 55022, FCC, and UL standards, making them ideal for communication and industrial systems. With a 3-year warranty, these compact, isolated modules deliver stable output voltages with high MTBF for demanding environments.
TRACO POWER TEN31222 Industrial Power Converter Specifications:
- Input voltage range: 4 VDC to 48 VDC
- Output voltages: 3.3 V, 5 V, 12 V, 15 V, 18 V, 24 V, 36 V, 72 V
- Maximum output currents: 600 mA to 250 mA depending on model
- Efficiency: Up to 84%
- Isolation voltage: 1500 VDC
- Operating temperature: -40°C to +85°C
- Ripple and noise: 60 mVpk-pk
- Electrical noise filtering: Meets EN 55022 A and FCC Level A
- MTBF: >1.1 million hours
- Short circuit protection: Yes, automatic recovery
- Dimensions: Compact, exact dimensions depend on model but conform to industry standards
- Weight: Approximately 12.4 g (0.44 oz)
- Maximum case temperature: +100°C
- Regulation: 0.5% max. variation from input and load changes
- Soldering temperature: Max. 265°C for 10 sec
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1
Buy the Tracopower TEN 31222 – Reliable High-Efficiency Industrial Power Converter
Order the Tracopower TEN 31222 online today and secure a high-efficiency, reliable isolated power supply suitable for industrial and communication systems. Designed to operate smoothly in demanding environments, it offers a wide input voltage range with short circuit protection, low noise, and compliance with international standards. With a compact size and long MTBF, this converter ensures your applications run reliably, reducing downtime and maintenance costs. Make your purchase now to benefit from fast delivery and trusted quality.
Buy Tracopower TEN 31222 now and experience unmatched reliability and performance for industrial power needs, ensuring stable voltage and high MTBF.
