TRACO POWER TML20124C Power Module
The TML 20124C is a compact, fully encapsulated AC/DC power module offering 20W power output with 24V DC voltage and 840mA current, suitable for space-critical industrial and commercial electronic applications. It features PCB or chassis mounting options with screw terminals, universal input (90-264VAC), and robust safety certifications including UL and IEC standards. The module provides excellent electromagnetic compatibility (EMC) compliance with EN 55022, class B, and includes protections such as short circuit, overload, and overvoltage. Its high efficiency, reliability, and safety make it ideal for diverse professional electronic projects.
TRACO POWER TML20124C Power Module Specifications:
- Output Power: 20 W
- Output Voltage: 24 VDC
- Output Current: 840 mA
- Input Voltage Range: 90-264 VAC
- Input Frequency: 47-440 Hz
- Efficiency: 74-84%
- Isolation Voltage: 3000 VAC
- Operating Temperature: -25°C to +70°C
- Storage Temperature: -40°C to +85°C
- Protection: Short circuit, overload, overvoltage
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1
- Compliance: EN 55022, FCC, EN 55024
- Housing Material: Plastic resin + fiberglass, UL 94V-0 rated
- Dimensions (mm): approx. 50 x 50 x 25 (L x W x H)
- Weight: approximately 325 g
- Switching Frequency: ~132 kHz
- Hold-up Time: 10 ms
Buy the Traco Power Series TML AC/DC Power Supply 20W: TML 20124C
Purchase the Traco Power TML 20124C online to benefit from a reliable, efficient power supply tailored for compact electronic projects. This 20W module offers 24V DC output with 840mA current, universal input, and compliance with international safety and EMC standards. Its robust protections include short circuit, overload, and overvoltage safeguards, ensuring durability in harsh environments. Ideal for industrial, commercial, and automation systems, ordering online guarantees fast delivery and access to technical support, making it the best choice for professional electronic assembly and maintenance.
Buy Traco Power TML 20124C now and experience unmatched reliability and performance with a high-quality, space-saving power module designed for industrial electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TML20124C?
You can click on the BUY or RFQ button to purchase TML20124C from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TML20124C?
You can download the TML20124C datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TML20124C?
TRACO POWER
